Swimlane Diagram Creation and Editing

Overview

Create and edit swimlane diagrams in JSON format. Diagrams consist of phases (columns), roles (rows), nodes (process steps), and connections (flow lines). The goal is producing diagrams that look human-drawn with natural alignment and clean connection lines.

Workflow Decision Tree

Creating New Diagram

Use "Creating a new diagram" workflow

Editing Existing Diagram

• •Fixing alignment/layout issues: Use "Editing layout" workflow
• •Adding/removing nodes: Use "Modifying content" workflow

Analyzing Diagram

Read JSON and use coordinate reference in coordinate-system.md

Creating a new diagram

Workflow

1. •Gather requirements: List all process steps, roles, phases, decision points
2. •Calculate dimensions: Use formulas in coordinate-system.md
3. •Place nodes: Follow natural alignment principles (vary X ±20px)
4. •Add connections: Ensure horizontal connections share same Y value
5. •Verify: Check all nodes within boundaries, connections straight

Quick Reference - JSON Structure

{
  "phases": [{"id": "p1", "name": "Phase Name", "width": 298}],
  "roles": [{"id": "r1", "name": "Role", "icon": "fa-icon", "color": "#hex", "height": 120}],
  "nodes": [{"id": "n1", "type": "task", "operation": "external", "label": "Task", "x": 344, "y": 142}],
  "connections": [{"from": "n1", "to": "n2", "fromSide": "bottom", "toSide": "top"}]
}

Editing layout

When fixing alignment or connection routing issues:

1. •Identify problems: Crooked lines = misaligned Y values; overflow = wrong dimensions
2. •Read coordinate reference: See coordinate-system.md for calculation formulas
3. •Apply fixes: Adjust coordinates following natural alignment principles
4. •Verify connections: Horizontal connections must have identical Y values

Modifying content

When adding/removing nodes:

1. •Update nodes array: Add/remove node objects
2. •Recalculate spacing: Adjust Y values to maintain ~60px spacing
3. •Update connections: Add/remove connection objects
4. •Adjust role heights: Recalculate if node count changed

Core Principles

Natural Alignment (NOT Rigid Grids)

❌ Rigid: X=320 for ALL nodes → looks mechanical
✅ Natural: X varies 302, 320, 334, 344 → looks human-drawn

Straight Connection Lines

• •Vertical flow: Nodes in same column must have close X values
• •Horizontal flow: Nodes MUST have identical Y value

Node Types & Operations

Common Mistakes

References

• •coordinate-system.md: Detailed coordinate calculation, dimension formulas, spacing rules
• •example-diagram.json: Complete working example showing typical patterns
