Physics & Collision
Collision Layer Standard
| Layer | Bit | Purpose | Body Type |
|---|---|---|---|
| 1 | 1 | Player body | CharacterBody2D |
| 2 | 2 | Player projectiles | Area2D |
| 3 | 4 | Player hitbox | Area2D |
| 4 | 8 | Enemy bodies | CharacterBody2D |
| 5 | 16 | Enemy projectiles | Area2D |
| 6 | 32 | Environment/walls | StaticBody2D |
| 7 | 64 | Pickups/items | Area2D |
| 8 | 128 | Triggers/zones | Area2D |
What Detects What
code
Player bullet (L2, M4) → detects enemy bodies (L4) Enemy bullet (L5, M1) → detects player body (L1) Player body (L1, M4|6) → collides with enemies + walls Enemy body (L4, M1|6) → collides with player + walls Pickup (L7, M1) → detects player body Trigger zone (L8, M1) → detects player entering
Physics Body Types
CharacterBody2D — Manual movement
gdscript
# For: player, enemies, NPCs
extends CharacterBody2D
func _physics_process(delta):
velocity = direction * speed
move_and_slide()
# After move_and_slide(), check:
# is_on_floor(), is_on_wall(), is_on_ceiling()
# get_slide_collision_count(), get_slide_collision(i)
RigidBody2D — Physics-driven
gdscript
# For: crates, balls, ragdoll, debris
extends RigidBody2D
func _ready():
mass = 2.0
gravity_scale = 1.0
func push(direction: Vector2, force: float):
apply_impulse(direction * force)
StaticBody2D — Immovable
gdscript
# For: walls, ground, platforms # Just add CollisionShape2D children # No script needed usually
Area2D — Detection only
gdscript
# For: bullets, pickups, triggers, hitboxes
extends Area2D
func _ready():
body_entered.connect(_on_body_entered) # Detects CharacterBody2D/RigidBody2D
area_entered.connect(_on_area_entered) # Detects other Area2D
body_exited.connect(_on_body_exited)
func _on_body_entered(body: Node2D):
if body.is_in_group("player"):
# Player entered this area
pass
Shape Types
gdscript
# Rectangle var rect = RectangleShape2D.new() rect.size = Vector2(32, 32) # Circle var circle = CircleShape2D.new() circle.radius = 16.0 # Capsule (for characters) var capsule = CapsuleShape2D.new() capsule.radius = 12.0 capsule.height = 32.0 # Segment (thin line, for raycasts/walls) var segment = SegmentShape2D.new() segment.a = Vector2(-50, 0) segment.b = Vector2(50, 0)
Setting Layers in Code
gdscript
# Direct assignment body.collision_layer = 1 # Layer 1 only body.collision_mask = 4 | 6 # Layers 3 and 4 (bits 4 + 32 = not right) # Actually, layers are bit positions: # Layer 1 = bit 1 = value 1 # Layer 2 = bit 2 = value 2 # Layer 3 = bit 3 = value 4 # Layer 4 = bit 4 = value 8 # Layer 5 = bit 5 = value 16 # Layer 6 = bit 6 = value 32 # So for "detect layers 4 and 6": body.collision_mask = 8 | 32 # = 40 # Helper: set specific layer body.set_collision_layer_value(1, true) # Enable layer 1 body.set_collision_mask_value(4, true) # Detect layer 4 body.set_collision_mask_value(6, true) # Detect layer 6
Common Collision Setups
Player
gdscript
player.collision_layer = 1 # Is on layer 1 player.set_collision_mask_value(4, true) # Detect enemies player.set_collision_mask_value(6, true) # Detect walls
Enemy
gdscript
enemy.collision_layer = 8 # Layer 4 (bit 4 = 8) enemy.set_collision_mask_value(1, true) # Detect player enemy.set_collision_mask_value(6, true) # Detect walls
Player Bullet
gdscript
bullet.collision_layer = 2 # Layer 2 bullet.collision_mask = 8 # Detect layer 4 (enemies)
Pickup
gdscript
pickup.collision_layer = 64 # Layer 7 pickup.collision_mask = 1 # Detect layer 1 (player)
RayCast2D (Line of Sight)
gdscript
var ray = RayCast2D.new()
ray.target_position = Vector2(200, 0) # Ray length and direction
ray.collision_mask = 1 | 32 # Detect player and walls
add_child(ray)
ray.enabled = true
# Check in _physics_process:
if ray.is_colliding():
var collider = ray.get_collider()
if collider.is_in_group("player"):
# Can see the player!
pass
One-Way Platforms
gdscript
# On StaticBody2D's CollisionShape2D: shape.one_way_collision = true # Player falls through from below, lands from above
Damage System Pattern
gdscript
# On anything that can be damaged
func take_damage(amount: int):
health -= amount
# Flash red
modulate = Color.RED
var tw = create_tween()
tw.tween_property(self, "modulate", Color.WHITE, 0.15)
if health <= 0:
die()
func die():
# Notify score system
var main = get_tree().current_scene
if main.has_method("add_score"):
main.add_score(100)
queue_free()
