Image First Frontend Build

Workflow

Follow this sequence every time:

P0. Tool capability preflight. 0. Detect mode (greenfield vs existing-system).

1. •Define scope and constraints.
2. •Run existing-system audit (when mode is existing-system).
3. •Define quality bar and anti-generic guardrails.
4. •Generate mockup directions (or deterministic fallback if image generation is unavailable).
5. •Select direction with weighted rubric.
6. •Extract design tokens and complete state matrix (required vs N/A).
7. •Build from the chosen direction and enforce performance budgets.
8. •Run objective QA gates, parity scoring, and artifact capture.
9. •Apply correction loops until acceptance criteria are met.

Operating Modes

Select one mode at the start of every run:

• •fast: Minimal verification for exploratory iteration and local design loops. Not sufficient for merge-ready signoff.
• •release: Full verification and evidence set. Required for merge-ready, CI, and audit-grade reports.

Step P0: Tool Capability Preflight

Before any design work, detect tool availability and record a chosen execution path:

• •Image generation available (yes/no).
• •Screenshot capture available (yes/no).
• •axe automation available (yes/no).
• •Operating mode selected (fast or release).

Execution path selection:

• •full: image generation + screenshots + axe available.
• •no-image: image generation unavailable; use structured text wireframe + token spec.
• •no-screenshot: screenshot capture unavailable; continue with explicit manual mismatch evidence.
• •no-axe: axe unavailable; run strict manual accessibility checklist and mark automation gap.
• •no-image+no-screenshot: image generation and screenshots unavailable.
• •no-image+no-axe: image generation unavailable and axe omitted.
• •no-screenshot+no-axe: screenshot capture unavailable and axe omitted.
• •no-image+no-screenshot+no-axe: image generation/screenshot capture unavailable and axe omitted.

Do not proceed until one path is explicitly selected.

Step 0: Mode Detection

Determine mode before style decisions:

• •greenfield: new or exploratory UI; choose a bold direction within product goals.
• •existing-system: preserve established design language and component patterns.

State the selected mode explicitly.

Step 1: Define Scope

Create a short design brief before prompt generation. Extract and confirm:

• •User goal (new app, new feature, or UI improvement).
• •Audience and primary task.
• •Target surfaces (page/component/modal + key states).
• •Breakpoints (minimum: 375, 768, 1024, 1440).
• •Brand constraints (colors, typography, spacing, tone).
• •Functional requirements (inputs, interactions, loading/error/empty states).
• •Content constraints (real content, realistic lengths, realistic empty/error copy).
• •Accessibility expectations (contrast, keyboard traversal, focus visibility).

If requirements are ambiguous, ask only the minimum clarifying questions needed to produce a useful mockup prompt.

Step 2: Existing-System Audit Checklist

Run this step only when mode is existing-system, before prompting:

• •Run the extractor script to build initial context:

node scripts/extract_design_system_context.mjs --repo-root . --baseline artifacts/ui-parity/<previous-run-id>/existing-system-context.json --out artifacts/ui-parity/<run-id>/existing-system-context.json

If this is the first existing-system run and <previous-run-id> is unavailable, omit --baseline; accept drift.level: "unknown" and require explicit signoff before implementation.

• •Review extracted tokens and reusable components.
• •Review reported design-system drift score and treat medium/high drift as a risk that needs explicit signoff.
• •Define explicit reuse targets:
  • •must-reuse
  • •allowed-extend
  • •do-not-change

Do not continue without explicit reuse targets in existing-system mode.

Step 3: Define Non-Negotiable Quality Bar

Before generating directions, set these non-negotiables:

• •Clear visual hierarchy (primary/secondary/tertiary content is obvious).
• •Distinct style direction (not generic template output).
• •Accessible interaction states (hover/focus/active/disabled visible).
• •Required states planned (default/loading/empty/error/success/disabled).
• •Mobile and desktop intent are both explicit.
• •Semantic structure is feasible (landmarks, headings, control semantics).

Content realism rule:

• •Ban pure lorem ipsum unless user explicitly requests it.
• •Use realistic labels, body copy lengths, and realistic error/empty messaging.

Step 4: Create Mockup Directions (or Deterministic Fallback)

Generate 2-3 distinct visual directions using available image generation.

Prompt templates live in references/mockup-prompt-templates.md.

If image generation is unavailable:

• •Create structured text wireframes (desktop + mobile hierarchy).
• •Produce token spec using assets/design-token-template.json.
• •Treat wireframe + token spec as the visual contract.

Step 5: Weighted Direction Selection Rubric

Score each direction using weighted criteria (0-5 each):

• •Clarity of hierarchy (35%).
• •Brand/system fit (30%).
• •Accessibility feasibility (20%).
• •Implementation cost (15%, higher score means lower cost/risk).

Compute weighted total and choose the highest-scoring direction.

Tie-breakers:

• •Prefer higher accessibility feasibility.
• •Then prefer lower implementation risk.

Use deterministic scoring script:

node scripts/score_mockup_directions.mjs --in artifacts/ui-parity/<run-id>/directions-input.json --out artifacts/ui-parity/<run-id>/direction-scores.json --md artifacts/ui-parity/<run-id>/direction-scores.md

Record the resulting scoring table in the output.

Step 6: Extract Design Tokens + State Matrix

Extract implementation tokens from the chosen direction:

• •Color system (background/surface/text/accent/semantic states).
• •Typography (families/scale/weights/line-height).
• •Spacing scale.
• •Radius/borders/shadows.
• •Motion tokens and reduced-motion behavior.

State matrix requirement:

• •For each key component/surface, map:
  • •default, loading, empty, error, success, disabled.
• •Mark each state as either:
  • •required (must be implemented), or
  • •N/A with written justification.

Store this matrix in artifacts/ui-parity/<run-id>/state-matrix.json and consume it during state coverage validation.

Rules:

• •Blank cells are not allowed.
• •N/A without justification fails acceptance.
• •Any required state missing in implementation fails acceptance.

Step 7: Build From Direction + Enforce Performance Budgets

Implement the frontend using the chosen direction as the contract.

Performance budgets (defaults, enforce pass/fail):

• •Route JavaScript budget: <= 250 KB (gzip/transfer equivalent).
• •Initial image payload budget: <= 800 KB.

Required behavior:

• •Motion fallback via prefers-reduced-motion.
• •Avoid heavy visual effects unless explicitly justified by the brief.

Step 8: Objective QA, Parity, and Artifacts

Run objective QA with script:

node scripts/run_ui_quality_gates.mjs --url http://localhost:3000 --mode <fast|release> --selected-path <full|no-image|no-screenshot|no-axe|no-image+no-screenshot|no-image+no-axe|no-screenshot+no-axe|no-image+no-screenshot+no-axe> --state-matrix artifacts/ui-parity/<run-id>/state-matrix.json --out-dir artifacts/ui-parity/<run-id>

Script expectations:

• •Test widths: 375, 768, 1024, 1440.
• •Run cross-browser gates across Chromium, WebKit, and Firefox in release mode.
• •Check horizontal overflow.
• •Check focus visibility and keyboard traversal baseline.
• •Run basic axe checks when available.
• •If axe is unavailable, compute WCAG AA contrast fallback in-page and fail on threshold violations.
• •Run stress gates in release mode: i18n/RTL, 200% zoom, reduced network, long-content overflow.
• •Run state discovery automation and fail when required states are untested.
• •Emit CI artifacts: JSON, JUnit XML, Markdown summary, run manifest with artifact hashes.
• •Validate output against references/quality-contract.schema.json.
• •Enforce anti-gaming constraints from references/anti-gaming-rules.md.

Accessibility thresholds (explicit):

• •WCAG AA contrast:
  • •normal text >= 4.5:1
  • •large text >= 3:1
• •Keyboard traversal:
  • •predictable Tab navigation through interactive controls
  • •no unexpected keyboard trap (except intentional modal traps)
  • •visible focus indicator on interactive controls
• •Reduced motion:
  • •with reduced-motion preference, non-essential animations are disabled or significantly reduced.

Scorecard (0-2 each, max 12):

• •Layout parity
• •Visual style parity
• •Interaction/state parity
• •Responsive parity
• •Accessibility quality
• •Distinctiveness (not generic/boilerplate)

Passing threshold:

• •No category below 1.
• •Total score >= 9.
• •All objective QA gates pass.
• •Performance budgets pass.

Run true visual parity scoring:

node scripts/compare_ui_screenshots.mjs --baseline-dir artifacts/ui-parity/<run-id>/screenshots/mockup --candidate-dir artifacts/ui-parity/<run-id>/screenshots/implementation --out-dir artifacts/ui-parity/<run-id> --mask-file artifacts/ui-parity/<run-id>/mask.json

Parity pass criteria:

• •Pixel diff ratio <= 0.02.
• •SSIM >= 0.96.

Standardized Evidence Artifacts

Use this structure for every run:

• •artifacts/ui-parity/<run-id>/qa-report.json
• •artifacts/ui-parity/<run-id>/run-manifest.json
• •artifacts/ui-parity/<run-id>/qa-junit.xml
• •artifacts/ui-parity/<run-id>/qa-summary.md
• •artifacts/ui-parity/<run-id>/mismatch-log.jsonl
• •artifacts/ui-parity/<run-id>/parity-report.json
• •artifacts/ui-parity/<run-id>/direction-scores.json
• •artifacts/ui-parity/<run-id>/state-coverage.json
• •artifacts/ui-parity/<run-id>/screenshots/mockup/<state>-w<width>.png
• •artifacts/ui-parity/<run-id>/screenshots/implementation/<state>-w<width>.png

run-id format: YYYYMMDD-HHMMSS.

Step 9: Correction Pass and Exit Criteria

Run up to 2 correction loops by default. If still below threshold, report blockers and next targeted fixes.

When a gate fails, use references/failure-remediation-map.md to apply targeted patches and rerun the minimal validating command set.

For release validation, run regression benchmark suite:

node scripts/run_skill_benchmark.mjs --tasks references/benchmark-tasks.md --run-dir artifacts/ui-parity/<run-id> --out artifacts/ui-parity/<run-id>/benchmark-report.json

Finish only when:

• •Chosen direction parity is strong on desktop and mobile.
• •Required states are implemented.
• •State matrix rules pass (required complete, N/A justified).
• •Accessibility thresholds pass.
• •Performance budgets pass.
• •Objective QA and score threshold pass.

Output Contract

When reporting completion, include:

• •Selected mode and preflight path.
• •Direction scoring table and chosen direction rationale.
• •Token summary.
• •State matrix (required/N/A + justification).
• •QA results and budget pass/fail summary.
• •Confidence score (high/medium/low) with reasons tied to gate results and tool coverage.
• •Existing-system drift score (when mode is existing-system).
• •Machine-contract validation results.
• •Artifact paths (QA report, mismatch log, screenshots).
• •Remaining gaps and rationale (if any).

References

• •references/mockup-prompt-templates.md: Prompt scaffolds for greenfield and existing-system directions.
• •references/quality-gates-checklist.md: Explicit gates, thresholds, and evidence checklist.
• •references/quality-contract.schema.json: Machine-checkable QA output contract.
• •references/pass-fail-examples.md: Calibrated examples of acceptable vs reject output quality.
• •references/failure-remediation-map.md: Gate-to-fix mapping with exact rerun commands.
• •references/anti-gaming-rules.md: Rules that prevent parity/QA manipulation.
• •references/benchmark-tasks.md: Regression benchmark task suite for this skill.
• •assets/design-token-template.json: Token schema for implementation and fallback mode.
• •scripts/run_ui_quality_gates.mjs: Automated QA runner.
• •scripts/extract_design_system_context.mjs: Existing-system token/component extractor.
• •scripts/crawl_ui_states.mjs: Reachable-state discovery and state-coverage gate.
• •scripts/score_mockup_directions.mjs: Deterministic direction ranking generator.
• •scripts/compare_ui_screenshots.mjs: Pixel/SSIM parity scorer with optional masks.
• •scripts/run_skill_benchmark.mjs: Runs benchmark suite and produces regression report.
