scaleinvariance Package Reference

Simulation and analysis tools for multifractal fields and time series.

Documentation: See CLAUDE.md in repository root.

Critical Usage Note

When analyzing multiple arrays (e.g., multiple time series or spatial snapshots), concatenate them along a NEW axis and pass ALL AT ONCE. Analysis functions are NOT linear operations - do NOT loop and accumulate results.

python

import numpy as np
import scaleinvariance

# Say we have 10 independent time series, each of length 2048
time_series_list = [generate_some_data() for _ in range(10)]

# CORRECT - stack along new axis (axis 0) and compute along original axis (axis 1)
stacked = np.stack(time_series_list, axis=0)  # Shape: (10, 2048)
H, err = scaleinvariance.structure_function_hurst(stacked, axis=1)  # Analyze along axis 1

# WRONG - do NOT loop and combine
# results = []
# for ts in time_series_list:
#     H, err = scaleinvariance.structure_function_hurst(ts)  # NO!
#     results.append(H)
# H_avg = np.mean(results)  # INCORRECT - these are not linear operations!

This applies to all analysis functions: structure_function_hurst, haar_fluctuation_hurst, spectral_hurst, two_point_intermittency_exponent, and their underlying *_analysis functions.

When to Use Which Function

Hurst Exponent Estimation

Task	Function	Notes
Recommended cases when 0<H<1	`structure_function_hurst`	First-order structure function scaling, robust
Wavelet-based alternative, works for -1<H<1	`haar_fluctuation_hurst`	Uses Haar wavelet convolution, first order
Spectral method, works for all H	`spectral_hurst`	Uses power spectrum β = 2H + 1, uses second-order statistics so will not be equivalent to the above for multifractal fields

All three methods estimate the same H parameter but may give slightly different results. Structure function is recommended for most cases.

Underlying Scaling Analysis

*Usually, the _hurst methods above are preferred to the functions in this section, as the spectrum/scaling function may be obtained from them using a kwarg described below

Task	Function	Notes
Structure function values	`structure_function_analysis`	Returns lags and S_n(r) values
Haar fluctuation values	`haar_fluctuation_analysis`	Returns lags and fluctuation values
Power spectral density	`spectral_analysis`	Returns binned frequencies and PSD

Intermittency Analysis

Task	Function	Notes
Estimate C1 parameter	`two_point_intermittency_exponent`	Uses two-point scaling to estimate intermittency
Compute K(q) function	`K`	Returns Lovejoy and Schertzer's K(q) = (C1/(alpha-1)) * (q^alpha - q)

Simulation

Task	Function	Notes
1D multifractal (FIF)	`FIF_1D`	Fractionally integrated flux with H, C1, alpha
N-D multifractal (FIF)	`FIF_ND`	2D, 3D, etc. with GSI support
1D fBm (spectral)	`fBm_1D_circulant`	Fast spectral synthesis, periodic
2D fBm (spectral)	`fBm_2D_circulant`	2D spectral synthesis, periodic
1D fBm (fractional integration)	`fBm_1D`	Extended H range (-0.5, 1.5)

Generalized Scale Invariance (GSI)

Task	Function	Notes
Anisotropic scale metric	`canonical_scale_metric`	Creates stratified/anisotropic distance metric, for use in FIF and fBm methods above

Backend Control

Task	Function	Notes
Set backend	`set_backend('numpy')` or `set_backend('torch')`	Torch is often much faster but is a huge dependency
Get backend	`get_backend()`	Returns current backend name
Set threads	`set_num_threads(n)`	Default: 90% CPU count

Function Signatures

Hurst Exponent Estimation

python

scaleinvariance.structure_function_hurst(
    data,               # N-dimensional array
    min_sep=None,       # Min lag for fit (default: 1 or 4 depending on size)
    max_sep=None,       # Max lag for fit (default: size/8 or size-1 if small)
    axis=0,             # Axis along which to compute
    return_fit=False    # If True, also return lags, values, fit_line
) -> (H, uncertainty) | (H, uncertainty, lags, sf_values, fit_line)

python

scaleinvariance.haar_fluctuation_hurst(
    data,               # N-dimensional array
    min_sep=None,       # Min lag for fit
    max_sep=None,       # Max lag for fit
    axis=0,             # Axis along which to compute
    return_fit=False    # If True, also return lags, values, fit_line
) -> (H, uncertainty) | (H, uncertainty, lags, haar_values, fit_line)

python

scaleinvariance.spectral_hurst(
    data,                    # N-dimensional array
    max_wavelength=None,     # Max wavelength for fit (default: size/8 or size)
    min_wavelength=None,     # Min wavelength for fit (default: 2 or 8)
    nbins=50,                # Number of log bins for PSD
    axis=0,                  # Axis along which to compute FFT
    return_fit=False         # If True, also return freqs, psd, fit_line
) -> (H, uncertainty) | (H, uncertainty, freqs, psd_values, fit_line)

Scaling Analysis Functions

python

scaleinvariance.structure_function_analysis(
    data,                    # N-dimensional array
    order=1,                 # Order n of structure function S_n(r)
    max_sep=None,            # Maximum lag to compute
    axis=0,                  # Axis along which to compute
    lags='powers of 1.2'     # 'all', 'powers of X', or array of lags
) -> (lags, sf_values)

python

scaleinvariance.haar_fluctuation_analysis(
    data,                    # N-dimensional array
    order=1,                 # Order of fluctuation
    max_sep=None,            # Maximum lag to compute
    axis=0,                  # Axis along which to compute
    lags='powers of 1.2',    # 'all', 'powers of X', or array of lags
    nan_behavior='raise'     # 'raise' or 'ignore'
) -> (lags, haar_values)

python

scaleinvariance.spectral_analysis(
    data,                    # N-dimensional array
    max_wavelength=None,     # Maximum wavelength to include
    min_wavelength=None,     # Minimum wavelength to include
    nbins=50,                # Number of log bins
    axis=0                   # Axis along which to compute FFT
) -> (binned_freq, binned_psd)

Intermittency Analysis

python

scaleinvariance.two_point_intermittency_exponent(
    data,                           # N-dimensional array
    order=2,                        # Second order for exponent (default: 2)
    assumed_alpha=2.0,              # Levy stability parameter (default: Gaussian)
    scaling_method='structure_function',  # or 'haar_fluctuation'
    min_sep=None,                   # Min separation for scaling
    max_sep=None,                   # Max separation for scaling
    axis=0                          # Axis along which to compute
) -> (C1, uncertainty)   # NOTE: uncertainty from error propagation is approximate

python

scaleinvariance.K(
    q,       # Order of moment (float or array)
    C1,      # Codimension of mean (intermittency parameter)
    alpha    # Levy stability parameter
) -> K_value   # K(q) = (C1/(alpha-1)) * (q^alpha - q)

FIF Simulation

python

scaleinvariance.FIF_1D(
    size,                      # Length (must be even, power of 2 recommended)
    alpha,                     # Levy stability parameter in (0, 2), != 1
    C1,                        # Codimension of mean (intermittency), must be > 0
    H,                         # Hurst exponent in (-1, 1)
    levy_noise=None,           # Pre-generated noise for reproducibility
    causal=True,               # Use causal kernels
    outer_scale=None,          # Large-scale cutoff (default: size)
    outer_scale_width_factor=2.0,  # Transition width control
    kernel_construction_method='LS2010',  # or 'naive', don't change this unless explicitely asked
    periodic=True              # Double size internally to eliminate artifacts
) -> numpy.ndarray   # Normalized by mean (or zero mean for H < 0)

python

scaleinvariance.FIF_ND(
    size,                      # Tuple of dimensions, e.g., (512, 512) or (256, 256, 128)
    alpha,                     # Levy stability parameter in (0, 2), != 1
    C1,                        # Codimension of mean (intermittency), must be > 0
    H,                         # Hurst exponent in (0, 1)
    levy_noise=None,           # Pre-generated noise for reproducibility
    outer_scale=None,          # Large-scale cutoff (default: max(size))
    outer_scale_width_factor=2.0,  # Transition width control
    kernel_construction_method='LS2010',  # Only LS2010 for N-D
    periodic=False,            # Bool or tuple of bool for per-axis periodicity
    scale_metric=None,         # Custom GSI distance metric
    scale_metric_dim=None      # Scaling dimension (default: spatial dimension)
) -> numpy.ndarray   # Normalized by mean

fBm Simulation

Circulant methods are preferred. fBm uses a convolution with a power law kernel similar to FIF, but this is not as accurate. However, fBm_1D can be used to limit the outer scale or control the noise, or make causal simulations, for example.

python

scaleinvariance.fBm_1D_circulant(
    size,      # Length (must be power of 2)
    H          # Hurst parameter (typical: 0-1, but negative supported)
) -> numpy.ndarray   # Zero mean, unit std, periodic

python

scaleinvariance.fBm_2D_circulant(
    size,      # (nx, ny) tuple or int for square (must be powers of 2)
    H          # Hurst parameter (typical: 0-1, but negative supported)
) -> numpy.ndarray   # Zero mean, unit std, periodic

python

scaleinvariance.fBm_1D(
    size,                      # Length (must be even, power of 2 recommended)
    H,                         # Hurst exponent in (-0.5, 1.5)
    causal=True,               # Use causal kernels
    outer_scale=None,          # Large-scale cutoff
    outer_scale_width_factor=2.0,
    periodic=True,             # Eliminate periodicity artifacts
    gaussian_noise=None,       # Pre-generated noise
    kernel_construction_method='naive'  # or 'LS2010'
) -> numpy.ndarray   # Zero mean, unit std

GSI Scale Metric

python

scaleinvariance.canonical_scale_metric(
    size,              # (nx, nz) for 2D or (nx, ny, nz) for 3D
    ls,                # Spheroscale (characteristic horizontal scale), must be > 0
    Hz=5/9             # Anisotropy exponent (default: atmospheric stratification)
) -> numpy.ndarray   # Scale metric with dx=2 spacing (matches LS2010 kernels)

IMPORTANT for GSI with FIF_ND: When using canonical_scale_metric, you must also specify scale_metric_dim:

•For 2D: scale_metric_dim = 1 + Hz
•For 3D: scale_metric_dim = 2 + Hz
•For 4D: scale_metric_dim = 3 + Hz
•...

python

# Example: 2D GSI simulation
size = (256, 256)
sim_size = (512, 512)  # Doubled for periodic=False
Hz = 0.556
ls = 100.0
metric = scaleinvariance.canonical_scale_metric(sim_size, ls=ls, Hz=Hz)
fif = scaleinvariance.FIF_ND(size, alpha=1.8, C1=0.1, H=0.3, periodic=False,
                              scale_metric=metric, scale_metric_dim=1 + Hz)

Parameter Interpretation

Hurst Exponent (H)

•H = 0.5: Random walk / uncorrelated increments
•H > 0.5: Persistent / positively correlated increments
•H < 0.5: Anti-persistent / negatively correlated increments
•FIF_1D supports H in (-1, 1); negative H gives differenced processes

Intermittency (C1)

•C1 = 0: No intermittency (Gaussian, monofractal)
•C1 > 0: Multifractal intermittency
•Typical atmospheric values: C1 ~ 0.05-0.2

Levy Stability (alpha)

•alpha = 2: Gaussian (log-normal multifractal)
•alpha < 2: Heavy-tailed (more extreme events)
•alpha = 1 is singular and not supported

Anisotropy (Hz)

•Hz = 1: Isotropic (standard Euclidean)
•Hz < 1: Stratified/layered structures (vertical scales slower)
•Hz = 5/9 ~ 0.556: Typical atmospheric stratification

Per-Axis Periodicity (FIF_ND)

Control periodicity separately for each axis:

python

# Periodic in x, non-periodic in z (for e.g., horizontal periodicity, vertical boundaries)
fif = scaleinvariance.FIF_ND((512, 256), alpha=1.7, C1=0.1, H=0.3,
                              periodic=(True, False))

Backend Selection

PyTorch backend provides speedups, often quite significant, for simulations:

python

import scaleinvariance

# Check current backend
print(scaleinvariance.get_backend())  # 'numpy' or 'torch'

# Force numpy backend
scaleinvariance.set_backend('numpy')

# Use torch if available (auto-detected by default)
scaleinvariance.set_backend('torch')

# Control threading
scaleinvariance.set_num_threads(8)

All functions return NumPy arrays regardless of backend.

Complete Examples

Estimate Hurst exponent with plotting

python

import numpy as np
import matplotlib.pyplot as plt
import scaleinvariance

# Generate test data
fif = scaleinvariance.FIF_1D(4096, alpha=1.8, C1=0.1, H=0.4)

# Estimate H with fit details
H, err, lags, sf, fit = scaleinvariance.structure_function_hurst(fif, return_fit=True)
print(f"H = {H:.3f} +/- {err:.3f}")

# Plot
plt.figure(figsize=(6, 4))
plt.loglog(lags, sf, 'o', label='Data')
plt.loglog(lags, fit, '-', label=f'Fit: H={H:.2f}')
plt.xlabel('Lag'); plt.ylabel('S_1(r)')
plt.legend(); plt.show()

Analyze multiple realizations correctly

python

import numpy as np
import scaleinvariance

# Generate multiple realizations
n_realizations = 20
size = 2048
H_true = 0.35

# Stack into 2D array: (n_realizations, size)
data = np.stack([
    scaleinvariance.FIF_1D(size, alpha=1.8, C1=0.1, H=H_true)
    for _ in range(n_realizations)
], axis=0)

# Analyze ALL at once, along axis 1
H_est, H_err = scaleinvariance.structure_function_hurst(data, axis=1)
print(f"Estimated H = {H_est:.3f} +/- {H_err:.3f} (true: {H_true})")

2D FIF with GSI anisotropy

python

import numpy as np
import matplotlib.pyplot as plt
import scaleinvariance

# Parameters
size = (256, 256)
Hz = 0.556  # Atmospheric stratification
ls = 50.0   # Spheroscale

# Create doubled domain for non-periodic simulation
sim_size = (512, 512)
metric = scaleinvariance.canonical_scale_metric(sim_size, ls=ls, Hz=Hz)

# Generate GSI multifractal
fif = scaleinvariance.FIF_ND(size, alpha=1.7, C1=0.1, H=0.3, periodic=False,
                              scale_metric=metric, scale_metric_dim=1 + Hz)

plt.figure(figsize=(6, 5))
plt.imshow(np.log(fif), cmap='viridis', aspect='auto')
plt.colorbar(label='log(FIF)')
plt.xlabel('x'); plt.ylabel('z (vertical)')
plt.title('Anisotropic GSI multifractal')
plt.show()
