10X Genomics Metadata Enricher

This skill enriches the validated dataset information by extracting additional metadata from each dataset's detail page.

Task

Read validated dataset JSON and Excel files, visit each dataset URL, and extract comprehensive metadata from the dataset detail pages to enrich the existing data.

Input Sources

The enricher reads from the validator's output directory:

  • •JSON: ../scraper/output/Data-10XGenomics-VisiumHD-Human.json
  • •Excel: ../scraper/output/Data-10XGenomics-VisiumHD-Human.xlsx

Note: The enricher should work with already-validated data to ensure data quality.

Metadata to Extract

From Dataset Overview → Imaging Section

Extract the following fields:

  1. •Biomaterials - Type of biomaterial used
  2. •Sample preparation - Sample preparation method details
  3. •Image type - Type of imaging (e.g., H&E, IF, etc.)
  4. •Microscope - Microscope model/manufacturer used
  5. •Objective magnification - Magnification level (e.g., 20X, 40X)
  6. •Numerical Aperture - Objective numerical aperture value
  7. •ScopeLED light source - Light source specifications
  8. •Camera - Camera model/specifications
  9. •Exposure - Exposure settings/time

From Right Panel (Sample Information)

Extract the following fields:

  1. •Species - Species information (if not already captured)
  2. •Anatomical Entity - Anatomical location/tissue
  3. •Preservation Method - Preservation method (FFPE, Fresh Frozen, etc.)
  4. •Disease State - Disease state or condition (e.g., Healthy, Cancer)
  5. •Biomaterial Type - Type of biomaterial (e.g., Tissue section)
  6. •Donor Count - Number of donors
  7. •Date Published - Publication date of the dataset

Output Format

The enricher generates enhanced versions of both JSON and Excel files with all original fields plus the new metadata fields.

Enhanced JSON Schema

json
[
  {
    "dataset_name": "string",
    "dataset_url": "string",
    "product": "string",
    "species": "string",
    "sample_type": "string",
    "cells_or_nuclei": "string",
    "preservation": "string",
    "biomaterials": "string",
    "sample_preparation": "string",
    "image_type": "string",
    "microscope": "string",
    "objective_magnification": "string",
    "numerical_aperture": "string",
    "scopeled_light_source": "string",
    "camera": "string",
    "exposure": "string",
    "anatomical_entity": "string",
    "preservation_method": "string",
    "disease_state": "string",
    "biomaterial_type": "string",
    "donor_count": "string",
    "date_published": "string"
  }
]

Enhanced Excel Output

The Excel output contains all fields as separate columns:

  • •Original columns: dataset_name, dataset_url, product, species, sample_type, cells_or_nuclei, preservation
  • •New Imaging columns: biomaterials, sample_preparation, image_type, microscope, objective_magnification, numerical_aperture, scopeled_light_source, camera, exposure
  • •New Sample Info columns: anatomical_entity, preservation_method, disease_state, biomaterial_type, donor_count, date_published

Directory Structure

code
skills/metadata_enricher/
├── SKILL.md                    # This file (agent instructions)
├── metadata_enricher.py        # Enricher script
└── output/                     # Enriched output files
    ├── Data-10XGenomics-VisiumHD-Human-Enriched.json
    └── Data-10XGenomics-VisiumHD-Human-Enriched.xlsx

Usage

Standalone Execution

bash
python metadata_enricher.py

Via Orchestrator

bash
# Run full pipeline (scraper + validator + enricher)
python ../../orchestrator.py

# Run only enricher (requires existing validated data)
python ../../orchestrator.py --skip-scraping --skip-validation

Command Line Options

bash
python metadata_enricher.py [OPTIONS]

Options:
  --json-path PATH        Path to input JSON file (default: ../scraper/output/Data-10XGenomics-VisiumHD-Human.json)
  --excel-path PATH       Path to input Excel file (default: ../scraper/output/Data-10XGenomics-VisiumHD-Human.xlsx)
  --output-dir PATH       Output directory for enriched files (default: ./output)
  --max-retries N         Max retries for failed page loads (default: 3)
  --timeout N             Timeout for page loads in seconds (default: 30)
  --parallel N            Number of parallel browser instances (default: 3)

Extraction Strategy

Page Structure Analysis

The script uses Selenium to:

  1. •Navigate to each dataset detail page
  2. •Wait for dynamic content to load
  3. •Locate the "Dataset Overview" section
  4. •Find the "Imaging" subsection within Dataset Overview
  5. •Extract key-value pairs from the Imaging section
  6. •Locate the right panel with sample information
  7. •Extract metadata from the sample info panel

Field Mapping

The script uses intelligent field mapping to handle variations in field names:

  • •Case-insensitive matching: "Biomaterials" vs "biomaterials"
  • •Label variations: "Objective Magnification" vs "Magnification"
  • •Flexible selectors: Multiple XPath/CSS selectors to accommodate page changes

Error Handling

  • •Missing fields: Record as empty string or "N/A"
  • •Page load failures: Retry up to max_retries times
  • •Parsing errors: Log error and continue with next field
  • •Network issues: Implement exponential backoff

Exit Codes

  • •0: All datasets enriched successfully
  • •1: Some datasets failed to enrich (partial success)
  • •2: Critical error (unable to read input files, no browser available, etc.)

Performance Considerations

  • •Parallel Processing: Process multiple URLs concurrently (default: 3 browsers)
  • •Browser Reuse: Reuse browser instances where possible
  • •Progress Tracking: Show real-time progress with ETA
  • •Caching: Cache extracted data to allow resume on failure
  • •Estimated Time: ~3-5 seconds per dataset (total ~1-3 minutes for 19 datasets)

Technical Details

  • •Browser Automation: Uses Selenium with headless Chrome
  • •Data Processing: Uses pandas for DataFrame manipulation
  • •Excel Export: Uses openpyxl for formatted Excel output with auto-sized columns
  • •Logging: Comprehensive logging to stderr with progress indicators
  • •Resume Support: Can resume from partial completion using checkpoint file

Modular Functions

The enricher is organized into modular functions:

  • •ensure_directories() - Creates output directory if needed
  • •load_input_data(json_path, excel_path) - Loads validated input files
  • •setup_driver() - Configures and initializes Chrome WebDriver
  • •extract_imaging_metadata(driver) - Extracts imaging section metadata
  • •extract_sample_info(driver) - Extracts right panel sample information
  • •enrich_single_dataset(dataset, max_retries, timeout) - Enriches one dataset
  • •enrich_all_datasets(datasets, max_workers, max_retries, timeout) - Enriches all datasets with parallel processing
  • •save_enriched_data(data, output_dir) - Saves enriched JSON and Excel files
  • •main() - Orchestrates the enrichment workflow

Agent Independence

This enricher agent:

  • •✅ Runs independently after validation
  • •✅ Reads validated input from file system
  • •✅ Can be executed standalone or via orchestrator
  • •✅ Produces structured output for downstream processing
  • •✅ Uses standard exit codes for pipeline integration
  • •✅ Does not modify original scraper/validator outputs (creates new files)

Data Quality

The enricher ensures data quality by:

  • •Validation: Only processes validated input data
  • •Consistency: Maintains all original fields unchanged
  • •Completeness: Attempts to extract all specified fields
  • •Traceability: Logs which fields were successfully extracted vs. missing
  • •Verification: Provides summary statistics on field completion rates

Notes

  • •The enricher adds NEW fields without modifying existing ones
  • •Original files remain unchanged; enriched data is saved separately
  • •Missing or unavailable fields are marked as empty strings
  • •The script handles dynamic page content using explicit waits
  • •Progress is reported to stderr, final status to stdout
  • •Can be re-run safely (idempotent operation)
