Tauri v2 Permissions Guide

This skill covers the Tauri v2 permissions and capabilities system, including plugin permissions, macOS-specific requirements, and common pitfalls.

Overview

Tauri v2 uses a Capabilities system to control what the frontend (WebView) can access. Each capability grants or denies specific permissions to windows.

code

┌─────────────────────────────────────────────────────────────────┐
│                    Tauri v2 Permission Flow                     │
├─────────────────────────────────────────────────────────────────┤
│   Frontend (JS)  ──▶  Tauri IPC  ──▶  Rust Backend              │
│        │                  │                 │                   │
│        └── Capabilities ──┴── Plugins ──────┘                   │
│                                                                 │
│   src-tauri/                                                    │
│   ├── capabilities/       ← Permission definitions              │
│   │   └── default.json                                          │
│   ├── Cargo.toml          ← Plugin dependencies                 │
│   ├── src/lib.rs          ← Plugin registration                 │
│   ├── Info.plist          ← macOS entitlements                  │
│   └── tauri.conf.json     ← App configuration                   │
└─────────────────────────────────────────────────────────────────┘

Capabilities Configuration

File Location

Capabilities are defined in src-tauri/capabilities/default.json (or additional files).

Basic Structure

json

{
  "$schema": "../gen/schemas/desktop-schema.json",
  "identifier": "default",
  "description": "Capability for the main window",
  "windows": ["main"],
  "permissions": [
    "core:default",
    "plugin-name:default",
    {
      "identifier": "plugin-name:specific-permission",
      "allow": [...],
      "deny": [...]
    }
  ]
}

Common Plugin Permissions

HTTP Plugin (`plugin-http`)

Cargo.toml:

toml

tauri-plugin-http = "2"

package.json:

json

"@tauri-apps/plugin-http": "^2.x"

lib.rs registration:

rust

.plugin(tauri_plugin_http::init())

Capabilities:

json

{
  "permissions": [
    "http:default",
    {
      "identifier": "http:allow-fetch",
      "allow": [
        { "url": "http://**" },
        { "url": "https://**" }
      ]
    }
  ]
}

[!WARNING] http:default alone does NOT allow arbitrary URLs. You MUST specify http:allow-fetch with URL patterns.

URL Patterns:

Pattern	Matches
`http://**`	All HTTP URLs
`https://**`	All HTTPS URLs
`http://localhost:/*`	localhost on any port
`http://192.168.:/**`	Local network (192.168.x.x)
`https://api.example.com/**`	Specific domain

File System Plugin (`plugin-fs`)

Capabilities:

json

{
  "permissions": [
    "fs:default",
    "fs:allow-appdata-read-recursive",
    {
      "identifier": "fs:allow-read",
      "options": {
        "scope": [
          "$APP_DATA/**",
          "$HOME/Documents/**"
        ]
      }
    },
    {
      "identifier": "fs:allow-write",
      "options": {
        "scope": ["$APP_DATA/**"]
      }
    }
  ]
}

Scope Variables:

Variable	Path
`$APP_DATA`	App data directory
`$HOME`	User home directory
`$TEMP`	Temp directory
`$DOWNLOAD`	Downloads folder

Updater Plugin (`plugin-updater`)

Capabilities:

json

{
  "permissions": ["updater:default"]
}

tauri.conf.json:

json

{
  "plugins": {
    "updater": {
      "pubkey": "YOUR_PUBLIC_KEY",
      "endpoints": [
        "https://github.com/user/repo/releases/latest/download/latest.json"
      ]
    }
  }
}

Other Common Plugins

Plugin	Permission	Description
`plugin-dialog`	`dialog:default`	Native dialogs (open/save)
`plugin-opener`	`opener:default`	Open URLs/files externally
`plugin-process`	`process:default`	Exit/relaunch app
`plugin-notification`	`notification:default`	System notifications
`plugin-clipboard`	`clipboard:default`	Clipboard access
`plugin-shell`	`shell:default`	Execute shell commands

macOS-Specific Requirements

Info.plist

Located at src-tauri/Info.plist. Tauri merges this with its generated plist.

App Transport Security (ATS)

[!CAUTION] macOS blocks HTTP connections by default. You MUST add this to allow non-HTTPS requests.

xml

<?xml version="1.0" encoding="UTF-8"?>
<!DOCTYPE plist PUBLIC "-//Apple//DTD PLIST 1.0//EN" "http://www.apple.com/DTDs/PropertyList-1.0.dtd">
<plist version="1.0">
<dict>
    <key>NSAppTransportSecurity</key>
    <dict>
        <key>NSAllowsArbitraryLoads</key>
        <true/>
        <key>NSAllowsLocalNetworking</key>
        <true/>
    </dict>
</dict>
</plist>

Common Usage Descriptions

xml

<dict>
    <!-- Microphone access -->
    <key>NSMicrophoneUsageDescription</key>
    <string>App needs microphone to record audio.</string>

    <!-- Camera access -->
    <key>NSCameraUsageDescription</key>
    <string>App needs camera for video calls.</string>

    <!-- Location access -->
    <key>NSLocationUsageDescription</key>
    <string>App needs location for local services.</string>

    <!-- Contacts access -->
    <key>NSContactsUsageDescription</key>
    <string>App needs contacts for sharing.</string>

    <!-- App Transport Security -->
    <key>NSAppTransportSecurity</key>
    <dict>
        <key>NSAllowsArbitraryLoads</key>
        <true/>
    </dict>
</dict>

Rust Backend Configuration

Plugin Registration (lib.rs)

rust

#[cfg_attr(mobile, tauri::mobile_entry_point)]
pub fn run() {
    tauri::Builder::default()
        .plugin(tauri_plugin_http::init())
        .plugin(tauri_plugin_fs::init())
        .plugin(tauri_plugin_dialog::init())
        .plugin(tauri_plugin_opener::init())
        .plugin(tauri_plugin_process::init())
        .plugin(tauri_plugin_updater::Builder::new().build())
        // ... other plugins
        .invoke_handler(tauri::generate_handler![...])
        .run(tauri::generate_context!())
        .expect("error while running tauri application");
}

Enabling DevTools in Release Builds

Cargo.toml:

toml

tauri = { version = "2", features = ["devtools"] }

lib.rs:

rust

.setup(|app| {
    use tauri::Manager;
    if let Some(window) = app.get_webview_window("main") {
        window.open_devtools();
    }
    Ok(())
})

Troubleshooting Checklist

"url not allowed on the configured scope"

•✅ Check capabilities/default.json has http:allow-fetch with correct URL pattern
•✅ Verify URL pattern uses ** wildcard correctly
•✅ Rebuild the app after changing capabilities

"App Transport Security policy requires secure connection"

•✅ Add NSAppTransportSecurity to Info.plist
•✅ Set NSAllowsArbitraryLoads to true
•✅ Rebuild the app (plist changes require rebuild)

Plugin not working

•✅ Verify plugin in Cargo.toml (Rust)
•✅ Verify plugin in package.json (JS)
•✅ Verify .plugin(...) call in lib.rs
•✅ Verify permission in capabilities/default.json

DevTools not opening in release

•✅ Add "devtools" to Tauri features in Cargo.toml
•✅ Call window.open_devtools() in setup hook
•✅ Remove #[cfg(debug_assertions)] guard if present

Quick Reference: New Plugin Checklist

When adding a new Tauri plugin:

•
Cargo.toml - Add Rust dependency
toml
```
tauri-plugin-NAME = "2"
```
•
package.json - Add JS dependency
json
```
"@tauri-apps/plugin-NAME": "^2.x"
```
•
lib.rs - Register plugin
rust
```
.plugin(tauri_plugin_NAME::init())
```
•
capabilities/default.json - Add permission
json
```
"NAME:default"
```

•

Info.plist (if macOS-specific permissions needed)

xml

<key>NSXxxUsageDescription</key>
<string>Reason...</string>

•
Rebuild - npm run tauri build or restart dev server
