Skill: Phase 2.B Bridge Safety & Idempotency

Scope: Backend relayer logic in services/, data model in migrations, Python/FastAPI code
When to activate: Phase 2.B implementation, deposit/withdrawal processing, merkle batch operations

Phase 2.B Stack Overview

code

deposits table (MySQL/Postgres) ← Event indexer reads here
    ↓
Batcher (pure function: SQL → merkle root)
    ↓
CronosSettlementAnchor (stores merkle root)
    ↓ (batch committed, now fetch merkle proofs for each withdrawal)
    ↓
CronosSigilLockbox (verify proofs + unlock SIGIL)

Critical Rule: Each step must be idempotent. Replaying the same operation twice must produce the same result and not double-spend.

Data Model Requirements

Table: `deposits`

sql

CREATE TABLE deposits (
    id SERIAL PRIMARY KEY,
    chain_id INT NOT NULL,           -- Which chain (e.g., Cronos testnet = 338)
    tx_hash VARCHAR(66) NOT NULL,    -- Source tx hash
    log_index INT NOT NULL,          -- Log index in tx (unique per tx)
    depositor VARCHAR(42) NOT NULL,  -- User address
    amount DECIMAL(36,18) NOT NULL,  -- Deposited amount (SIGIL)
    recipient VARCHAR(42) NOT NULL,  -- Execution chain recipient
    block_number BIGINT NOT NULL,    -- Confirmations counted from here
    confirmed_at TIMESTAMP,          -- When confirmations reached 5+
    minted_at TIMESTAMP,             -- When SIGIL minted (proof verified)
    status ENUM('DETECTED', 'CONFIRMED', 'MINTED') DEFAULT 'DETECTED',
    error_reason TEXT,               -- If minting failed

    UNIQUE(chain_id, tx_hash, log_index),  -- ← CRITICAL: Prevents duplicate ingestion
    INDEX(status),
    INDEX(confirmed_at)
);

Idempotency Pattern:

python

# Querying deposits
deposits = db.query(Deposits).filter(
    Deposits.status == 'DETECTED',
    Deposits.confirmed_at == None,
    Deposits.block_number <= current_block - 5  # Confirmation depth
).limit(10)

# Processing (IDEMPOTENT)
for dep in deposits:
    # Before changing status, verify prerequisites
    if dep.status != 'DETECTED':
        continue  # Skip already processed

    try:
        # Mint SIGIL
        mint_tx = bridge_service.mint_deposit(dep)
        dep.status = 'MINTED'
        dep.minted_at = datetime.now()
    except Exception as e:
        dep.error_reason = str(e)
        dep.status = 'FAILED'  # Mark explicitly, don't retry

    db.commit()  # Atomic: all or nothing

Table: `withdrawals`

sql

CREATE TABLE withdrawals (
    id SERIAL PRIMARY KEY,
    chain_id INT NOT NULL,           -- Source chain (execution layer)
    tx_hash VARCHAR(66) NOT NULL,    -- Burn tx hash
    log_index INT NOT NULL,          -- Log index in tx
    withdrawer VARCHAR(42) NOT NULL, -- User address
    amount DECIMAL(36,18) NOT NULL,  -- Withdrawal amount
    recipient VARCHAR(42) NOT NULL,  -- Cronos recipient (where SIGIL unlocked)
    block_number BIGINT NOT NULL,    -- Confirmations counted from here
    confirmed_at TIMESTAMP,          -- When confirmations reached 5
    batched_at TIMESTAMP,            -- When included in batch
    executed_at TIMESTAMP,           -- When proof verified + unlocked
    status ENUM('DETECTED', 'CONFIRMED', 'BATCHED', 'EXECUTED', 'FAILED') DEFAULT 'DETECTED',
    error_reason TEXT,
    batch_id BIGINT,                 -- Which batch contains this withdrawal
    merkle_proof JSON,               -- Merkle proof (cached for execution)

    UNIQUE(chain_id, tx_hash, log_index),  -- ← CRITICAL: Prevents double-processing
    INDEX(status),
    INDEX(batch_id),
    FOREIGN KEY(batch_id) REFERENCES batches(id)
);

Table: `batches`

sql

CREATE TABLE batches (
    id BIGINT PRIMARY KEY,           -- Sequential batch ID (1, 2, 3, ...)
    merkle_root VARCHAR(66) NOT NULL,
    total_amount DECIMAL(36,18) NOT NULL,  -- Sum of all withdrawals
    leaf_count INT NOT NULL,         -- Number of withdrawals in batch
    created_at TIMESTAMP,            -- When batch was computed
    anchored_at TIMESTAMP,           -- When merkle root submitted to chain
    finalized_at TIMESTAMP,          -- When all proofs executed
    status ENUM('CREATED', 'ANCHORED', 'FINALIZED') DEFAULT 'CREATED',

    UNIQUE(merkle_root),             -- ← CRITICAL: Prevents duplicate roots
    INDEX(status)
);

Table: `batch_leaves`

sql

CREATE TABLE batch_leaves (
    id SERIAL PRIMARY KEY,
    batch_id BIGINT NOT NULL,        -- Which batch
    withdrawal_id BIGINT NOT NULL,   -- Which withdrawal
    leaf_index INT NOT NULL,         -- Position in merkle tree (0-indexed)
    leaf_hash VARCHAR(66) NOT NULL,  -- keccak256(withdrawal_id, recipient, amount)

    UNIQUE(batch_id, withdrawal_id), -- Each withdrawal in only 1 batch
    UNIQUE(batch_id, leaf_index),    -- Each position filled once
    FOREIGN KEY(batch_id) REFERENCES batches(id),
    FOREIGN KEY(withdrawal_id) REFERENCES withdrawals(id)
);

Table: `processed_events` (Global Deduplication)

sql

CREATE TABLE processed_events (
    id SERIAL PRIMARY KEY,
    event_source VARCHAR(255) NOT NULL,  -- "chain_id:tx_hash:log_index"
    event_type VARCHAR(50) NOT NULL,    -- 'DEPOSIT', 'WITHDRAWAL', 'RESOLUTION'
    processed_at TIMESTAMP DEFAULT NOW(),

    UNIQUE(event_source)  -- ← CRITICAL: Only process once, ever
);

Core Idempotency Patterns

Pattern 1: UNIQUE Constraint (Prevent Duplicate Ingestion)

python

# Event indexer
def ingest_deposit_events(block_range):
    """
    Idempotent: Safe to call multiple times on same block range.
    Duplicate events will hit UNIQUE constraint and be ignored.
    """
    for event in fetch_events_from_rpc(block_range):
        try:
            db.deposits.insert({
                'chain_id': event.chain_id,
                'tx_hash': event.tx_hash,
                'log_index': event.log_index,  # ← Makes (chain_id, tx_hash, log_index) unique
                'amount': event.amount,
                'status': 'DETECTED'
            })
        except IntegrityError:
            # Already ingested. Skip.
            continue

    db.commit()

Result: Even if RPC returns same event twice, database enforces single-insert.

Pattern 2: State-Based Idempotency (Check Before Acting)

python

# Minting deposits
def process_confirmed_deposits():
    """
    Idempotent: Safe to call multiple times. Only processes DETECTED deposits.
    """
    deposits = db.query(Deposits).filter(
        Deposits.status == 'DETECTED',
        Deposits.confirmed_at.isnot(None)
    )

    for dep in deposits:
        # Check status BEFORE acting
        if dep.status != 'DETECTED':
            continue  # Already processed, skip

        try:
            mint_receipt = bridge_service.mint(amount=dep.amount, to=dep.recipient)
            dep.status = 'MINTED'
            dep.minted_at = datetime.now()
            db.commit()
        except Exception as e:
            db.rollback()
            # Don't retry indefinitely; mark as failed
            dep.status = 'FAILED'
            dep.error_reason = str(e)
            db.commit()

Result: Rerun same function; it skips already-MINTED deposits, avoiding double-mint.

Pattern 3: Smart Contract Guards (Final Validation)

solidity

// CronosSettlementAnchor.sol
require(!withdrawalClaims[withdrawalId].claimed, "Already claimed");

// CronosSigilLockbox.sol
require(totalLocked >= amount, "Insufficient locked balance");

Result: Even if backend re-submits same withdrawal proof, contract rejects it.

Pattern 4: Merkle Proof Replay Prevention

python

# Batcher (compute merkle tree)
def create_batch(withdrawal_ids):
    """
    Pure function: No DB state, no side effects.
    Always produces SAME merkle root for SAME input set.
    """
    withdrawals = [db.withdrawals[wid] for wid in withdrawal_ids]
    leaves = [
        keccak256(bytes(
            abi.encodePacked(w.id, w.recipient, w.amount)
        ))
        for w in withdrawals
    ]
    root = merkle_tree(leaves).root
    return root  # ← Deterministic, idempotent

Executor (replay prevention):

python

def execute_withdrawal_proof(withdrawal_id, recipient, amount, proof, batch_id):
    """
    Calls CronosSigilLockbox.withdraw(withdrawal_id, recipient, amount, proof, batch_id)

    Idempotency: Smart contract rejects if:
      1. withdrawalClaims[withdrawal_id].claimed == True (already executed)
      2. merkle_root doesn't match stored batch commitment
    """
    tx = contract.functions.withdraw(
        withdrawal_id,
        recipient,
        amount,
        proof,  # bytes32[] array
        batch_id
    ).transact()

    # Wait for confirmation
    receipt = w3.eth.wait_for_transaction_receipt(tx)

    if receipt.status == 1:  # Success
        withdrawal = db.withdrawals[withdrawal_id]
        withdrawal.status = 'EXECUTED'
        withdrawal.executed_at = datetime.now()
        db.commit()
    else:
        # Transaction failed; don't retry same call
        withdrawal.status = 'FAILED'
        withdrawal.error_reason = f"Contract reverted: {receipt}"
        db.commit()

Confirmation Depth Rule

Even on Cronos testnet, require 5+ block confirmations before acting:

python

def find_confirmable_deposits():
    """
    Only process deposits with 5+ block confirmations.
    """
    current_block = w3.eth.block_number
    confirmable = db.query(Deposits).filter(
        Deposits.status == 'DETECTED',
        Deposits.confirmed_at == None,
        Deposits.block_number <= current_block - 5  # At least 5 blocks deep
    )

    for dep in confirmable:
        dep.confirmed_at = datetime.now()
        db.commit()

    return len(confirmable)

Reasoning:

•Handles micro-reorgs (1-2 blocks)
•Survives validator crashes + recovery
•Applies same rule to Phase 2.A (Cronos-only) and Phase 3 (Solana)

Batch Sequencing Rules

Batches MUST be sequential: 1, 2, 3, 4, ...

python

def create_next_batch(max_size=1000):
    """
    Create batch N+1 ONLY after batch N is ANCHORED.
    """
    latest_batch = db.query(Batches).order_by(Batches.id.desc()).first()

    if latest_batch:
        if latest_batch.status != 'ANCHORED':
            raise ValueError(f"Batch {latest_batch.id} not anchored yet. Cannot create next batch.")
        next_batch_id = latest_batch.id + 1
    else:
        next_batch_id = 1

    # Collect confirmed (not yet batched) withdrawals
    withdrawals = db.query(Withdrawals).filter(
        Withdrawals.status == 'CONFIRMED',
        Withdrawals.batch_id == None
    ).limit(max_size)

    if not withdrawals:
        return None

    # Compute merkle root
    root = compute_merkle_root([w for w in withdrawals])

    # Create batch
    batch = Batches(
        id=next_batch_id,
        merkle_root=root,
        total_amount=sum(w.amount for w in withdrawals),
        leaf_count=len(withdrawals),
        status='CREATED'
    )

    for w in withdrawals:
        w.batch_id = next_batch_id
        w.status = 'BATCHED'

    db.add(batch)
    db.commit()

    return batch

Why Sequential?

•Prevents gaps (Batch 1, Batch 3, Batch 5... is fragile)
•Orders withdrawals deterministically (same inputs → same root)
•Makes debugging easier (Batch N always contains batched withdrawals N)

Dry-Run Mode

python

# In relayer.py
class Relayer:
    def __init__(self, dry_run=False):
        self.dry_run = dry_run  # If True, compute but don't submit

    def execute_withdrawals(self):
        # Get pending withdrawals
        withdrawals = self.get_pending()

        for w in withdrawals:
            proof = self.merkle_utils.get_proof(w.batch_id, w.leaf_index)

            if self.dry_run:
                # Simulate without submitting
                is_valid = self.verify_proof_locally(proof, w)
                if is_valid:
                    print(f"[DRY RUN] Would execute withdrawal {w.id}")
                else:
                    raise ValueError(f"Proof invalid for {w.id}")
            else:
                # Submit for real
                tx_hash = self.submit_withdrawal_tx(w, proof)
                w.tx_hash = tx_hash
                db.commit()

Usage:

bash

# Test without submitting
python relayer.py --dry-run

# Test with real submissions
python relayer.py --live

Logging Granularity

Every state change MUST log:

python

import logging

logger = logging.getLogger(__name__)

def process_deposit(dep):
    logger.info(
        "Processing deposit",
        extra={
            'deposit_id': dep.id,
            'tx_hash': dep.tx_hash,
            'block_number': dep.block_number,
            'amount': str(dep.amount),
            'recipient': dep.recipient
        }
    )

    try:
        receipt = bridge_service.mint(dep.amount, dep.recipient)

        logger.info(
            "Deposit minted successfully",
            extra={
                'deposit_id': dep.id,
                'mint_tx_hash': receipt.transactionHash,
                'gas_used': receipt.gasUsed,
                'block_number': receipt.blockNumber
            }
        )

        dep.status = 'MINTED'
        dep.minted_at = datetime.now()

    except Exception as e:
        logger.error(
            "Deposit mint failed",
            extra={
                'deposit_id': dep.id,
                'error': str(e),
                'error_type': type(e).__name__
            },
            exc_info=True
        )
        dep.status = 'FAILED'
        dep.error_reason = str(e)

    db.commit()

Logs should enable monitoring:

•✅ Early detection of stuck bathes
•✅ Gas cost trending
•✅ Error rate spikes
•✅ Reorg detection (block reorgs cause tx_hash changes)

Cross-Platform Merkle Compatibility

Python and JavaScript MUST produce identical roots:

bash

# Verification test (run before any merkle change)
cd verification/

# Python
python python-merkle-test.py

# JavaScript
node cross-platform-merkle-test.js

# Compare outputs
# Expected: Both output same merkle root hash

Relayer State Machine (ASCII Diagram)

code

DEPOSIT FLOW:
┌─────────────────────────────────────────────────┐
│ RPC Event: DepositLocked(id, amount, recipient) │
└─────────────────────┬───────────────────────────┘
                      │
                      ▼
            Indexer: Store in deposits table
            Status: DETECTED
                      │
         Wait 5+ block confirmations
                      │
                      ▼
    Minter: Check deposit.status == 'DETECTED'
             Call bridge_service.mint()
             Update deposits.status = 'MINTED'
                      │
                      ▼
        ✅ Success (or mark FAILED, don't retry)

WITHDRAWAL FLOW:
┌────────────────────────────────────────────────┐
│ RPC Event: WithdrawalBurned(id, amount, to)    │
└─────────────────────┬────────────────────────────┘
                      │
                      ▼
            Indexer: Store in withdrawals table
            Status: DETECTED
                      │
         Wait 5+ block confirmations
                      │
                      ▼
    Batcher: Collect all CONFIRMED withdrawals
             Compute merkle tree + root
             Insert batch into batches table
             Create batch_leaves entries
             Update withdrawals.status = 'BATCHED'
                      │
                      ▼
    Anchor: Submit merkle root to CronosSettlementAnchor
            Update batches.status = 'ANCHORED'
                      │
                      ▼
    Executor: For each BATCHED withdrawal
              Compute merkle proof (from tree)
              Call CronosSigilLockbox.withdraw(proof, ...)
              Update withdrawals.status = 'EXECUTED'
                      │
                      ▼
    ✅ Success (or mark FAILED, check contract error)

Monitoring & Alerts

Alert if:

• Batch creation delayed > 10 minutes
• Merkle root anchoring failed (tx reverted)
• Withdrawal proof execution failure > 5% of batch
• Reorg detected (block reorgs cause deposit/withdrawal tx_hash to change)
• Confirmation depth violations (deposits processed before 5 blocks)
• Database constraint violations (UNIQUE violations)

Test Scenarios

python

def test_idempotent_deposit_ingestion():
    """Ingesting same deposit twice should not double-process."""
    deposit_event = make_event(tx_hash="0xABC", log_index=0)

    # Ingest once
    ingest_events([deposit_event])
    assert db.count(Deposits) == 1

    # Ingest again
    ingest_events([deposit_event])
    assert db.count(Deposits) == 1  # Still 1, not 2

def test_idempotent_minting():
    """Reminting same deposit should not double-mint."""
    dep = create_deposit(amount=100, status='DETECTED')

    # Mint once
    process_confirmed_deposits()
    assert db.deposits[dep.id].status == 'MINTED'

    # Mint again (should skip)
    process_confirmed_deposits()
    assert db.deposits[dep.id].status == 'MINTED'  # Still MINTED, not error

def test_merkle_proof_replay():
    """Executing same withdrawal proof twice should fail on second attempt."""
    withdrawal = create_withdrawal(id=42, amount=100)
    proof = compute_merkle_proof(withdrawal)

    # Execute once
    execute_withdrawal(withdrawal, proof)
    assert contract.withdrawalClaims[42].claimed == True

    # Execute again (should revert on-chain)
    try:
        execute_withdrawal(withdrawal, proof)
        assert False, "Should have reverted"
    except ContractRevertError:
        pass  # Expected

def test_batch_sequencing():
    """Batches must be sequential; cannot create batch N+2 before N+1."""
    batch_1 = create_batch(id=1, root="0xAAA")

    try:
        batch_3 = create_batch(id=3, root="0xCCC")
        assert False, "Should not allow gap"
    except ValueError as e:
        assert "Batch 1 not anchored" in str(e)

References

•PHASE_2B_RELAYER.md — Full Phase 2.B specification
•deposits/withdrawals/batches schema — Data model details
•merkle_utils.py — Cross-platform merkle tree implementation
•bridge_service.py — Deposit/withdrawal orchestration

Skill: Phase 2.B Bridge Safety & Idempotency

Phase 2.B Stack Overview

Data Model Requirements

Table: deposits

Table: withdrawals

Table: batches

Table: batch_leaves

Table: processed_events (Global Deduplication)

Core Idempotency Patterns

Pattern 1: UNIQUE Constraint (Prevent Duplicate Ingestion)

Pattern 2: State-Based Idempotency (Check Before Acting)

Pattern 3: Smart Contract Guards (Final Validation)

Pattern 4: Merkle Proof Replay Prevention

Confirmation Depth Rule

Batch Sequencing Rules

Dry-Run Mode

Logging Granularity

Cross-Platform Merkle Compatibility

Relayer State Machine (ASCII Diagram)

Monitoring & Alerts

Test Scenarios

References

Table: `deposits`

Table: `withdrawals`

Table: `batches`

Table: `batch_leaves`

Table: `processed_events` (Global Deduplication)
