Windows UI Automation Control

This skill enables you to control Windows desktop applications through a gRPC-based automation server. It uses Approach 2: App Structure (LLM-Friendly) for efficient "See → Think → Act" loops.

Prerequisites

•UiAutomationGRPC.Server running (default: localhost:50051)
•grpccurl installed (for direct gRPC calls)

Security Configuration

The server supports two security modes. You must configure grpccurl accordingly.

Insecure Mode (Development/Testing)

When the server is running with Security.Enabled: false (default for development):

bash

# Use -plaintext flag for HTTP connections
grpccurl -plaintext -d '{"app_name": "calc"}' localhost:50051 UiAutomation.UiAutomationService/GetAppStructure

Secure Mode (Production)

When the server is running with Security.Enabled: true:

bash

# Use HTTPS (no -plaintext flag) + TLS certificate verification
grpccurl -cacert server.crt -d '{"app_name": "calc"}' localhost:50051 UiAutomation.UiAutomationService/GetAppStructure

# Or skip certificate verification (not recommended for production)
grpccurl -insecure -d '{"app_name": "calc"}' localhost:50051 UiAutomation.UiAutomationService/GetAppStructure

Token Authentication

When the server has Security.TokenAuthEnabled: true, include the authorization header:

bash

# Add -H for Authorization header with Bearer token
grpccurl -plaintext \
  -H "Authorization: Bearer YOUR_SECRET_TOKEN" \
  -d '{"app_name": "calc"}' \
  localhost:50051 UiAutomation.UiAutomationService/GetAppStructure

Combined Secure + Token Auth:

bash

grpccurl -insecure \
  -H "Authorization: Bearer YOUR_SECRET_TOKEN" \
  -d '{"app_name": "calc"}' \
  localhost:50051 UiAutomation.UiAutomationService/GetAppStructure

Note: If you receive Unauthenticated errors, verify:

•The token matches one in the server's Security.ValidTokens array

•The header format is exactly Authorization: Bearer <token>

The Loop: See → Think → Act

code

┌─────────────────────────────────────────────────────────┐
│  1. SEE    → GetAppStructure (get full UI as JSON)      │
│  2. THINK  → Analyze JSON, find target element UniqId   │
│  3. ACT    → PerformActionWithStructure (action + new UI)│
│  4. REPEAT → Response includes updated UI, continue     │
└─────────────────────────────────────────────────────────┘

Commands

Get App Structure (SEE)

Retrieve the complete UI tree of an application.

bash

grpccurl -plaintext -d '{"app_name": "calc"}' localhost:50051 UiAutomation.UiAutomationService/GetAppStructure

Parameters:

Parameter	Description
`app_name`	Process name (e.g., "calc", "notepad")
`process_id`	Alternative: use PID instead
`use_process_id`	Set `true` to use PID lookup

Returns: json_structure containing the UI tree.

Understanding AppNode

json

{
  "UniqId": "42,12345",           // ← Use this for actions
  "Name": "Five",                 // Display name
  "UiAutomationId": "num5Button", // Stable identifier
  "ControlType": "ControlType.Button",
  "BoundingRectangle": "x,y,w,h",
  "IsClickable": true,
  "IsVisible": true,
  "Children": [ ... ]
}

Perform Action with Structure (ACT)

This is the key method for the loop - performs an action AND returns the updated UI structure.

bash

grpccurl -plaintext -d '{"runtime_id": "YOUR_UNIQ_ID", "action": 9}' localhost:50051 UiAutomation.UiAutomationService/PerformActionWithStructure

Parameters:

Parameter	Description
`runtime_id`	The `UniqId` from the JSON
`action`	Action code (see table below)
`arguments`	Optional string array

Action Reference

Action	Code	Use Case	Arguments
INVOKE	0	Default action (buttons)	-
TOGGLE	1	Checkboxes, switches	-
SET_VALUE	4	Type text	`["text"]`
SET_FOCUS	5	Focus element	-
MoveTo	8	Move mouse to element	-
LeftClick	9	Click (recommended)	-
RightClick	10	Right-click	-
DoubleClick	17	Double-click	-

Example: Calculator 9 × 9

bash

# 1. Open calculator (if not running)
grpccurl -plaintext -d '{"app_name": "calc"}' localhost:50051 UiAutomation.UiAutomationService/OpenApp

# 2. Get structure → Find "Nine" button UniqId
grpccurl -plaintext -d '{"app_name": "calc"}' localhost:50051 UiAutomation.UiAutomationService/GetAppStructure

# 3. Click "9" → Returns updated structure
grpccurl -plaintext -d '{"runtime_id": "42,xxx", "action": 9}' localhost:50051 UiAutomation.UiAutomationService/PerformActionWithStructure

# 4. Click "×" → Find multiply button, click it
grpccurl -plaintext -d '{"runtime_id": "42,yyy", "action": 9}' localhost:50051 UiAutomation.UiAutomationService/PerformActionWithStructure

# 5. Click "9" again
grpccurl -plaintext -d '{"runtime_id": "42,xxx", "action": 9}' localhost:50051 UiAutomation.UiAutomationService/PerformActionWithStructure

# 6. Click "=" → Get result from display element
grpccurl -plaintext -d '{"runtime_id": "42,zzz", "action": 9}' localhost:50051 UiAutomation.UiAutomationService/PerformActionWithStructure

Other Useful Methods

Method	Description
`OpenApp`	Launch application by path/name
`CloseApp`	Close by process name
`CloseAppByProcessId`	Close by PID
`SendKeys`	Send keyboard input
`TakeScreenshot`	Capture window/element

Troubleshooting

Issue	Solution
App not found	Ensure app is running; use OpenApp first
Element not found	UniqIds are runtime-specific; re-fetch structure
Access denied	Run server with Admin privileges
Server unreachable	Verify `UiAutomationGRPC.Server` is running on 50051
SSL connection error	Server uses HTTP; add `-plaintext` flag to grpccurl
Certificate error	Use `-insecure` flag or provide valid `-cacert`
`Unauthenticated`	Token auth enabled; add `-H "Authorization: Bearer TOKEN"`
`Invalid token`	Verify token is in server's `Security.ValidTokens` list
