SKILL: XCUIAutomation — Critical iOS Workflow Testing

Summary

This skill is an expert in XCUIAutomation (XCUITest) for iOS applications, with a strict focus on validating critical user workflows.

It prioritizes:

• •Deterministic UI automation
• •Accessibility-driven querying
• •End-to-end workflow validation
• •Maintainable, low-flakiness tests

It explicitly rejects snapshot, screenshot, or visual-diff testing.

Scope & Non-Goals

In Scope

• •XCUIAutomation / XCUITest
• •XCUIApplication lifecycle control
• •XCUIElementQuery querying strategies
• •XCUIElement interaction & assertions
• •Testing real user flows (login, onboarding, CRUD, navigation)

Out of Scope

• •Screenshot testing
• •Snapshot testing
• •Pixel comparison
• •Visual diffing
• •Internal UIKit / SwiftUI state inspection

All validation must be done via observable UI behavior.

Core Philosophy

1. •Test workflows, not views
2. •Assert behavior, not appearance
3. •Query by accessibility, never layout
4. •Fail fast, fail clearly
5. •Flakiness is a design bug

Mental Model

XCUIAutomation tests the app out-of-process, through the accessibility layer.

You are not:

• •Calling UIKit
• •Touching SwiftUI
• •Inspecting internal state

You are:

• •Acting as a real user
• •Discovering elements via accessibility
• •Interacting via taps, typing, gestures
• •Verifying externally observable results

Core Types & Responsibilities

XCUIApplication

Represents the application under test.

Responsibilities:

• •Launching and terminating the app
• •Acting as the root element query
• •Managing launch arguments and environment

Example:

let app = XCUIApplication()
app.launch()

Best Practices:

• •Launch once per test unless isolation requires otherwise
• •Use launch arguments to control app state
• •Never assume initial UI state without asserting it

XCUIElementQuery

Used to locate UI elements.

Principles:

• •Prefer accessibility identifiers
• •Avoid positional queries
• •Use predicates for dynamic content
• •Always narrow queries intentionally

Good:

app.buttons["loginButton"]

Acceptable:

app.cells.containing(.staticText, identifier: "Task").firstMatch

Avoid:

app.otherElements.element(boundBy: 3)

XCUIElement

Represents a concrete UI element.

Primary Capabilities:

• •Interaction (tap, typeText, swipe)
• •State validation (exists, isHittable, value)
• •Synchronization (waitForExistence)

Golden Rule: Never interact with an element before asserting it exists.

Example:

let submit = app.buttons["Submit"]
XCTAssertTrue(submit.waitForExistence(timeout: 5))
submit.tap()

Test Structure Pattern

All tests should follow this structure:

1. •Arrange – launch app and assert starting state
2. •Act – perform user interactions
3. •Assert – verify resulting UI state
4. •Isolate – leave no shared state behind

Example:

func testUserCanLogIn() {
    let app = XCUIApplication()
    app.launch()

    let username = app.textFields["username"]
    XCTAssertTrue(username.waitForExistence(timeout: 5))
    username.tap()
    username.typeText("testuser")

    let password = app.secureTextFields["password"]
    password.tap()
    password.typeText("password")

    app.buttons["login"].tap()

    XCTAssertTrue(app.staticTexts["Welcome"].waitForExistence(timeout: 5))
}

Assertions: What Is Valid

Valid Assertions:

• •Element existence
• •Element hittability
• •Navigation completion
• •Text values
• •Enabled / disabled state
• •Alerts appearing
• •Screen transitions

Invalid Assertions:

• •Screenshot comparisons
• •Pixel alignment
• •Font size
• •Color checks
• •Layout spacing

If a user cannot perceive it functionally, it should not be asserted.

Synchronization Rules

Required:

• •waitForExistence(timeout:) for async UI
• •Assertions before interactions

Forbidden:

• •sleep()
• •Arbitrary delays
• •Timing-based assumptions

Accessibility Requirements

This skill assumes:

• •Every critical interactive element has a stable accessibility identifier
• •Identifiers are semantic, not visual

Bad: button1

Good: addTaskButton

If an element is hard to test, fix accessibility, not the test.

Navigation & Gestures

Supported interactions:

• •tap()
• •typeText(_:)
• •swipeUp() / swipeDown()
• •press(forDuration:)

Avoid gesture-heavy flows unless they are core to the app experience.

Handling Flakiness

Flakiness is addressed by:

• •Strong queries
• •Explicit waits
• •Clear state assertions
• •Test isolation

Never fix flakiness by:

• •Increasing timeouts blindly
• •Adding sleeps
• •Retrying without understanding failure

Performance Tests

Performance tests:

• •Should not use @MainActor
• •Must avoid artificial serialization
• •Measure real user-visible behavior only

Example:

measure(metrics: [XCTApplicationLaunchMetric()]) {
    XCUIApplication().launch()
}

Actor & Concurrency Rules

• •UI tests do not require @MainActor
• •XCUIAutomation is already serialized and synchronized
• •Use @MainActor only in unit tests touching app code directly

Example Workflows to Automate

• •App launch & first render
• •Authentication (login / logout)
• •Onboarding completion
• •Creating, editing, deleting data
• •Tab & navigation flows
• •Error handling & validation states

Each workflow must:

• •Start from a known state
• •End with a clear assertion
• •Be readable without comments

Final Rule

If a test does not prove that a user can complete a critical task, it does not belong in the UI test suite.
