Manuscript Preprocessor v3.1

Raw manuscript → Structured chunks + Quality validators + Pre-flight checks → Ready for /research v5.2 iteration

Overview

This skill converts a raw manuscript (pasted from Word/Docs) into review-ready chunks optimized for LLM token budgets, plus 3 lightweight quality validators and pre-flight checks that guide the review process.

Design Principles

•Token-budget aware: Each chunk ≤ 4,000 tokens of manuscript text
•Context-preserving: Every chunk carries a context header summarizing other sections
•Sequential iteration: Results → Discussion → Introduction → Abstract (dependencies flow upward)
•Lightweight validation: Markdown tables, not JSON schemas

Phase 1: Format Cleanup

Step 1: Metadata Extraction

Extract from first ~15 lines → YAML front matter:

•title, authors, affiliations, keywords, journal

Step 2: Structure Normalization

•Title → # Title
•Major sections → ## Section
•Subsections → ### Subsection

Step 3: Equation Conversion

•Inline: E_z, |E/E_0|^4 → $E_z$ , $|E/E_0|^4$
•Display: standalone → $$...\quad\text{(Eq. N)}$$

Step 4: Cleanup

•Delete  comments
•Clean figure regions → > **[Figure N]**: caption
•Mark SI references → [SI: Fig. SX — not reviewed]
•Remove excessive empty lines
•Normalize references

Output: draft_v1.md (full preprocessed manuscript)

Phase 2: Chunk & Freeze

Freeze List (不迭代)

These sections are extracted and saved separately. They do NOT enter the review loop:

•frozen/metadata.yaml — authors, affiliations, acknowledgements
•frozen/methods.md — Methods section (optional R6 review)
•frozen/references.md — Reference list (REQUIRED for Reference Coverage Audit in Phase 3b)
•frozen/si_references.md — SI reference inventory

⚠️ v3.1: frozen/references.md MUST contain the complete reference list. If the manuscript does not have a parseable reference section, generate a stub file listing all in-text citation numbers and warn: "Reference audit will be partial — full list needed."

Chunk Strategy

Target: each chunk ≤ 4,000 tokens (to fit within ~8K total review budget)

Split the manuscript into review chunks:

Chunk	Content	Iteration Order	Figure Captions
`chunk_A.md`	Title + Abstract	5th (last)	None
`chunk_B.md`	Introduction	4th	None
`chunk_C.md`	Results §1 (by Figure grouping)	1st	Include in chunk body
`chunk_D.md`	Results §2 (by Figure grouping)	2nd	Include in chunk body
`chunk_E.md`	Discussion	3rd	Referenced figures' captions

v3 change: Figure captions are now included in the chunk body (not just as references). This ensures captions are reviewed alongside the text that references them.

Adaptive splitting for Results: Group by ### subsection headings or by Figure discussion. If a single group > 4,000 tokens, split at paragraph boundaries.

Context Header

Every chunk gets a context header (adds ~200-500 tokens):

yaml

---
chunk: "[section name]"
parent: "[paper title]"
iteration_order: N of 5
preceding_sections_summary: |
  [2-3 sentence summary of sections that come BEFORE this one in the paper]
following_sections_summary: |
  [2-3 sentence summary of sections that come AFTER this one in the paper]
figures_in_chunk: [Fig. X, Fig. Y]
equations_in_chunk: [Eq. X, Eq. Y]
key_claims_in_chunk: [claim_ids from claim_evidence_matrix]
---

Important for Abstract (chunk_A): Since Abstract is iterated LAST, its context header must contain the latest summaries of all other chunks (updated after their iterations complete).

Iteration Order Rationale

code

Results (C,D) → Discussion (E) → Introduction (B) → Abstract (A)

•Results first: These are facts. They change least but set the foundation.
•Discussion second: Interprets Results. Must align with what Results actually show.
•Introduction third: Frames the gap and claim. Must match what Results delivered.
•Abstract last: Distills everything. Must reflect the final state of all sections.

Phase 3: Lightweight Validators

Validator 1: `claim_evidence_matrix.md`

Generated during Step 0. Referenced in every review round.

Extract every claim from the manuscript and map to evidence:

markdown

# Claim-Evidence Matrix

| # | Claim (verbatim quote) | Section | Evidence | Evidence Type | Strength | Flag |
|---|---|---|---|---|---|---|
| C1 | "20 dB suppression of side-lobes" | Results | Fig. 3b | Direct | ✅ Strong | — |
| C2 | "transforms TERS from luck-based art" | Abstract | None | Assertion | ⚠️ Unsupported | Soften |
| C3 | "~15-fold enhancement" | Abstract | Fig. 4b shows 17× | Direct | ⚠️ Inconsistent | Check |
| C4 | "fundamental LSP mode" | Results | FDTD field map | Simulation | ✅ Moderate | Needs modal decomp |

## Evidence Type (NEW in v3)
- **Direct**: Experimental measurement with quantified result
- **Simulation**: FDTD, FEM, or other computational result
- **Theoretical**: Derived from theory/equations without direct measurement
- **Assertion**: No supporting evidence provided (opinion, rhetoric)

> ⚠️ **Auto-flag rule**: Any claim where `Evidence Type = Assertion` or `Theoretical` that supports a **core finding** → auto-flag as P1 during R1.

## Strength Levels
- ✅ **Strong**: Direct experimental data, properly quantified
- ✅ **Moderate**: Supported by simulation or indirect measurement
- ⚠️ **Weak**: Logical inference without direct data
- ⚠️ **Unsupported**: No evidence provided
- ❌ **Overclaim**: Claim exceeds what data shows

## Phrasing Guide (for overclaim detection)
- ✅ Cautious: "suggests", "is consistent with", "we attribute X to Y"
- ⚠️ Strong: "demonstrates", "proves", "shows that"
- ❌ Absolute: "always", "never", "completely", "perfectly"

Validator 2: `novelty_statement.md`

Extract all novelty-related sentences ("Here we show", "for the first time", "we demonstrate"):

markdown

# Novelty Audit

## Claimed Novelty Statements
1. "[exact quote]" (Section: Introduction, Line: N)
   - **Prior art**: [relevant references that partially address this]
   - **Delta**: [what is genuinely new vs. incremental]
   - **Verdict**: ✅ Novel / ⚠️ Incremental / ❌ Already shown

## Missing Positioning
- [Areas where the paper should differentiate from prior work but doesn't]

Validator 3: `consistency_checklist.md`

Generated during Reassembly (Step 6). Checks cross-chunk consistency:

markdown

# Consistency Checklist

## Terminology
| Term Variant A | Term Variant B | Chosen Standard | Chunks Affected |
|---|---|---|---|
| "AO ON" | "AO-ON" | "AO ON" | C, D, E |

## Numerics
| Value in Section A | Value in Section B | Match? | Action |
|---|---|---|---|
| "~15-fold" (Abstract) | "17×" (Results) | ❌ | Reconcile |

## Cross-References
| Reference | Target Exists? | Correct? |
|---|---|---|
| "as shown in Fig. 2c" | Fig. 2c caption exists | ✅ |

Phase 3b: Pre-Flight Checks (NEW in v3)

Run BEFORE iteration starts:

Check 1: Global Overclaim Scan

Scan all chunks for absolute language:

•Keywords: "transforms", "proves", "perfectly", "first-ever", "unique", "always", "never"
•For each occurrence: flag + require explicit evidence type
•Output: append flags to claim_evidence_matrix.md

Check 2: Discussion Structure Skeleton

Verify chunk_E contains (or pre-populate skeleton for):

•¶1 — Summary of key findings
•¶2 — Significance and broader impact
•¶3 — Limitations
•¶4 — Future directions

If any missing → pre-populate skeleton text marked

Check 3: Limitations Pre-check

If chunk_E has no limitations content → flag as P0 before iteration starts.

Check 4: Target Journal Calibration

Record target journal in metadata YAML:

yaml

target_journal: "Nature Photonics"
impact_tone: "paradigm-shifting but precise"

This affects impact tone during R5 (Nature-Level Final Pass).

Check 5: Reference Coverage Audit

Scan reference list (frozen/references.md) and manuscript body:

•For each ### subsection: are key references in that sub-field cited?
•Year distribution: flag if <30% of references are from the last 3 years
•Self-citation ratio: flag if >25% are from the same group
•Missing competing groups: identify uncited groups working in the same area
•Output: reference_audit.md with gaps and suggestions

Check 6: Required Sections Audit (NEW in v3.1)

Verify the following exist in the manuscript or frozen/ sections:

•✅ Data Availability Statement (Nature Photonics requires it)
•✅ Code Availability Statement (if computational work present)
•✅ Author Contributions
•✅ Competing Interests Declaration
•If ANY missing → flag as P0, add to author_queries.md with exact wording template

Phase 3c: Chunk Complexity Estimator (v3.1)

For each chunk, compute a complexity score with section-type multiplier:

code

Base score = word_count/500 + equations×2 + figures×1.5 + claims_weighted

Claims weighting by section type:
  Discussion:    claims × 1.5 × 0.5  (overclaim risk is higher)
  Abstract:      claims × 1.2 × 0.5  (each word carries more weight)
  Introduction:  claims × 1.0 × 0.5  (standard)
  Results:       claims × 0.8 × 0.5  (fact-dense, lower overclaim risk)

Score → min_rounds mapping:
  < 3  → min_rounds = 3  (e.g., Abstract)
  3-6  → min_rounds = 5  (e.g., Introduction, Discussion)
  > 6  → min_rounds = 6  (e.g., Results with equations)

Record in each chunk's context header as complexity_score and min_rounds.

Complete Pipeline Summary

code

Raw Manuscript
    │
    ▼ Phase 1: Format Cleanup
    ├── draft_v1.md (full preprocessed)
    │
    ▼ Phase 2: Chunk & Freeze
    ├── frozen/ (metadata, methods, references[required], SI)
    ├── chunk_A.md through chunk_E.md (with context headers + figure captions)
    │
    ▼ Phase 3: Validators
    ├── claim_evidence_matrix.md (with evidence_type column)
    ├── novelty_statement.md
    │
    ▼ Phase 3b: Pre-Flight Checks
    ├── Global overclaim scan → flags in claim_evidence_matrix
    ├── Discussion structure skeleton → chunk_E validation
    ├── Limitations pre-check → P0 if missing
    ├── Target journal calibration → metadata
    ├── Reference coverage audit → reference_audit.md
    ├── Required sections audit → P0 if Data Availability missing (v3.1)
    │
    ▼ Phase 3c: Chunk Complexity Estimator (section-type multiplier, v3.1)
    ├── Complexity score per chunk → dynamic min_rounds
    │
    ▼ /research v5.2 workflow takes over
    │   R0: Non-Expert Readability pre-screen (chunk_A only)
    │   Per-chunk iteration: C → D → E → B → A
    │   Dynamic rounds (min per complexity, max 10)
    │   R2: Structured diff output + [PLACEHOLDER:AQ-N] format
    │   R3: Missing Controls + Suggested Protocols + Alt. Methodology
    │   R3 sub-rounds don't count toward main round
    │   Early acceptance (≥3 approvals + R3 + min-1 rounds)
    │   revision_history compression at round 7+ (R3 never compressed)
    │   Auto-collects DEFERRED + Missing Controls → author_queries.md
    │
    ▼ Global Quality Gate + Reviewer Risk Score (v5.2)
    │   Claim-Evidence audit, Novelty, Reference coverage, Missing Controls
    │   Risk score per chunk: HIGH/MED/LOW
    │
    ▼ Reassembly
    ├── consistency_checklist.md (+ equation numbering check, v5.2)
    ├── final_manuscript.md (with transition sentences)
    ├── author_queries.md (auto-collected)
    │
    ▼ Post-processing
    ├── Figure-Text Alignment check (+ panel format verification)
    ├── Adversarial Reviewer (Reviewer #3)
    ├── Cover Letter + Significance Statement
    └── Methods Audit
