Design System Patterns
Headless Component Libraries
| Library | Framework | Bundle | Styling | Accessibility |
|---|---|---|---|---|
| Radix UI | React | Per-component | Unstyled | Full WAI-ARIA |
| Headless UI | React/Vue | ~10kb | Unstyled | Full WAI-ARIA |
| Ark UI | React/Vue/Solid | Per-component | Unstyled | Full WAI-ARIA |
| React Aria | React | Per-hook | Unstyled | Full WAI-ARIA |
Default: Radix UI for React projects needing broad primitive coverage. Headless UI for simpler needs or Vue support.
Component API Design
Compound Components
typescript
// Expose composable parts — consumer controls layout
const Select = { Root, Trigger, Content, Item, Value }
// Usage: full layout control
<Select.Root value={val} onValueChange={setVal}>
<Select.Trigger><Select.Value placeholder="Pick one" /></Select.Trigger>
<Select.Content>
{items.map(i => <Select.Item key={i.value} value={i.value}>{i.label}</Select.Item>)}
</Select.Content>
</Select.Root>
Polymorphic as Prop
typescript
type PolymorphicProps<E extends React.ElementType, P = {}> = P &
Omit<React.ComponentPropsWithRef<E>, keyof P> & { as?: E }
function Box<E extends React.ElementType = 'div'>({ as, ...props }: PolymorphicProps<E>) {
const Comp = as || 'div'
return <Comp {...props} />
}
// Renders as <a> with anchor props
<Box as="a" href="/about">About</Box>
Variant System (CVA)
typescript
import { cva, type VariantProps } from 'class-variance-authority'
const badge = cva('inline-flex items-center rounded-full font-medium', {
variants: {
variant: {
default: 'bg-primary/10 text-primary',
success: 'bg-green-100 text-green-800 dark:bg-green-900 dark:text-green-200',
warning: 'bg-yellow-100 text-yellow-800 dark:bg-yellow-900 dark:text-yellow-200',
error: 'bg-red-100 text-red-800 dark:bg-red-900 dark:text-red-200',
},
size: { sm: 'px-2 py-0.5 text-xs', md: 'px-2.5 py-0.5 text-sm', lg: 'px-3 py-1 text-base' },
},
defaultVariants: { variant: 'default', size: 'md' },
})
export type BadgeProps = React.HTMLAttributes<HTMLSpanElement> & VariantProps<typeof badge>
export function Badge({ className, variant, size, ...props }: BadgeProps) {
return <span className={cn(badge({ variant, size }), className)} {...props} />
}
Design Tokens
css
/* Token hierarchy: primitive → semantic → component */
:root {
/* Primitives */
--color-blue-500: 217 91% 60%;
--color-gray-100: 220 14% 96%;
/* Semantic */
--color-primary: var(--color-blue-500);
--color-surface: var(--color-gray-100);
/* Component */
--button-bg: hsl(var(--color-primary));
--card-bg: hsl(var(--color-surface));
/* Spacing scale (4px base) */
--space-1: 0.25rem; --space-2: 0.5rem; --space-3: 0.75rem;
--space-4: 1rem; --space-6: 1.5rem; --space-8: 2rem;
/* Typography */
--font-sans: 'Inter', system-ui, sans-serif;
--text-sm: 0.875rem; --text-base: 1rem; --text-lg: 1.125rem;
}
.dark {
--color-primary: 217 91% 70%;
--color-surface: 220 14% 14%;
}
Gotchas
- •Style encapsulation: CSS Modules or Tailwind scoping avoid global class collisions; CSS-in-JS adds runtime cost
- •SSR + CSS-in-JS: Libraries like styled-components need server-side style extraction; prefer CSS variables for zero-JS theming
- •Accessibility defaults: Headless libraries handle ARIA; never override
roleoraria-*attributes they set - •Prop API bloat: Prefer compound components over deeply nested config objects -- easier to extend and tree-shake
- •Token naming: Use semantic names (
--color-primary) not visual (--color-blue) -- enables theming
Cross-References
- •frontend:tailwind-design-system -- Tailwind-specific token config, CVA patterns, and dark mode setup
- •frontend:accessibility-testing -- WCAG compliance testing for component libraries
