Educational Demo Test Case Developer

Develop test cases that verify LEARNING, not just clicking buttons.

Core Philosophy

A test case should answer: "Did the demo teach this concept correctly?"

NOT: "Did this button work?"

Workflow

Step 1: Understand the Concept

code

Read(problems/<name>/problem.md)

Identify:

•What concept is being taught?
•What are the KEY OPERATIONS a learner must understand?
•What misconceptions should be avoided?

Step 2: Define Learning Outcomes

For each operation, define what a learner should UNDERSTAND:

code

OPERATION: Insert into heap
LEARNER SHOULD SEE:
  - New element appears at bottom
  - Element "bubbles up" through comparisons
  - Element stops when heap property satisfied
LEARNER SHOULD UNDERSTAND:
  - Why we compare with parent
  - When to stop bubbling
  - Time complexity (visually: height of tree)

Step 3: Design Test Scenarios

Each scenario tests a specific learning outcome:

json

{
  "scenario": "insert_small_value",
  "purpose": "Verify bubble-up is shown correctly",
  "setup": "Start with heap [10, 20, 30]",
  "action": {
    "type": "insert",
    "value": 1
  },
  "verify": {
    "visual": "Value 1 moves from bottom to root",
    "state": "Final heap: [1, 10, 30, 20]",
    "learning": "User sees WHY 1 bubbles all the way up"
  }
}

Step 4: Prototype with Chrome Tools

Use Chrome tools to verify interactions work:

code

# Get tab context
mcp__claude-in-chrome__tabs_context_mcp(createIfEmpty=true)

# Navigate to demo
mcp__claude-in-chrome__navigate(url="file:///path/to/demo.html", tabId=X)

# Read page structure
mcp__claude-in-chrome__read_page(tabId=X, filter="interactive")

# Find elements
mcp__claude-in-chrome__find(query="insert button", tabId=X)

# Take screenshot of initial state
mcp__claude-in-chrome__computer(action="screenshot", tabId=X)

# Interact
mcp__claude-in-chrome__form_input(ref="ref_X", value="1", tabId=X)
mcp__claude-in-chrome__computer(action="left_click", ref="ref_Y", tabId=X)

# Screenshot after action
mcp__claude-in-chrome__computer(action="screenshot", tabId=X)

Test Case Categories

1. Happy Path (Basic Operations)

•Normal insert
•Normal extract/delete
•Standard traversal

2. Edge Cases

•Empty structure
•Single element
•Full/overflow conditions

3. Learning Moments

•When does the algorithm make an "interesting" decision?
•What if we insert a value that doesn't need to move?
•What if we extract when there's only one element?

4. Misconception Prevention

•Common wrong assumptions
•Cases where intuition fails

Output Format

Write to: problems/<name>/test_cases.json

json

{
  "problem": "heap-demo",
  "concept": "Min-Heap Operations",
  "test_cases": [
    {
      "id": "insert_bubble_up",
      "category": "happy_path",
      "name": "Insert causes bubble-up",
      "purpose": "Verify learner sees bubble-up animation",
      "preconditions": {
        "initial_state": "heap with [10, 20, 30, 40]"
      },
      "steps": [
        {"action": "find", "query": "value input field"},
        {"action": "input", "value": "5"},
        {"action": "find", "query": "insert button"},
        {"action": "click"},
        {"action": "wait", "ms": 2000},
        {"action": "screenshot", "name": "after_insert"}
      ],
      "verify": {
        "visual": "5 should bubble up past 20 and 10",
        "expected_state": "heap is [5, 10, 30, 40, 20]",
        "learning_check": "Animation shows comparison at each level"
      }
    },
    {
      "id": "extract_root",
      "category": "happy_path",
      "name": "Extract root shows bubble-down",
      "purpose": "Verify learner sees bubble-down process",
      "steps": [
        {"action": "find", "query": "extract button"},
        {"action": "click"},
        {"action": "wait", "ms": 2000},
        {"action": "screenshot", "name": "after_extract"}
      ],
      "verify": {
        "visual": "Last element moves to root, then bubbles down",
        "learning_check": "Shows comparison with BOTH children"
      }
    }
  ]
}

Integration with Evaluator

The evaluator will:

•Read test_cases.json
•Execute each test case using Chrome tools
•Verify visual/state expectations
•Score based on learning outcomes achieved

Built-in Screenshot Capture

The base.html demo includes automatic screenshot capture. When prototyping test cases:

You don't need to manage screenshots manually. The demo provides:

•window.screenshotManager.captureState(label) - programmatic capture
•"📸 Capture State" button - manual capture during interaction
•"⬇️ Download Screenshots" button - download all as PNGs

Use the button for manual captures while prototyping. Builders can integrate captureState() calls into their algorithm for automatic captures.

Prototyping Tips

When using Chrome tools to prototype:

•Read the page first - understand what elements exist
•Use find - locate elements by purpose, not implementation
•Screenshot liberally - capture before/after states
•Check viewport - ensure all elements visible without scroll
•Test edge cases - try breaking the UI

Example Chrome Session

code

# Initial setup
tabs_context_mcp(createIfEmpty=true) -> tabId: 123

# Navigate
navigate(url="file:///Users/.../agent_1.html", tabId=123)

# Read structure
read_page(tabId=123, filter="interactive")
-> Shows: [ref_1: input, ref_2: button "Insert", ref_3: button "Extract"]

# Prototype insert test
form_input(ref="ref_1", value="5", tabId=123)
computer(action="screenshot", tabId=123) -> "before_insert.png"
computer(action="left_click", ref="ref_2", tabId=123)
computer(action="wait", duration=2, tabId=123)
computer(action="screenshot", tabId=123) -> "after_insert.png"

# Read screenshots to verify
Read(before_insert.png)
Read(after_insert.png)
# Does it show the bubble-up correctly?
