Forsion Login Integration

This skill guides you through integrating frontend applications with the Forsion unified backend authentication system.

When to Use This Skill

Use this skill when:

•Integrating a new frontend project with Forsion backend authentication
•Setting up login, registration, or password reset flows
•Implementing JWT token management
•Configuring API clients with authentication headers
•Troubleshooting authentication issues

Important: JWT Token vs JWT Secret

Frontend applications ONLY need JWT tokens, NOT the JWT_SECRET:

Concept	Who Uses	What Is It
JWT Token	Frontend / All API clients	A string returned by `/api/auth/login` that must be sent in the `Authorization: Bearer <token>` header for all authenticated API calls
JWT Secret (JWT_SECRET)	Backend server only	A secret key stored in backend `.env` used to sign and verify tokens. NEVER share with or configure in frontend

Frontend Integration Summary:

•Call login API → Receive token string in response
•Save token to localStorage
•Send token in Authorization: Bearer <token> header for ALL authenticated API requests
•Frontend does NOT need, and should NOT have access to, JWT_SECRET

Which APIs need the token?

•Login/Register APIs: No token needed (you call these to GET a token)
•All other APIs: Token required (user info, credits, payments, storage, AI chat, etc.)

If you are asked to configure "JWT_SECRET" in frontend, that is incorrect. Frontend only uses the token string.

Quick Start Integration (3 Steps)

Step 1: Create Auth Utility

Create src/utils/authRedirect.ts (or .js for JavaScript projects):

typescript

const AUTH_BASE_URL = import.meta.env.VITE_AUTH_URL || 'http://localhost:3001/auth';
const TOKEN_KEY = 'auth_token';

export function initAuth(): boolean {
  const urlParams = new URLSearchParams(window.location.search);
  const tokenFromUrl = urlParams.get('token');

  if (tokenFromUrl) {
    localStorage.setItem(TOKEN_KEY, tokenFromUrl);
    urlParams.delete('token');
    const newUrl = urlParams.toString()
      ? `${window.location.pathname}?${urlParams}`
      : window.location.pathname;
    window.history.replaceState({}, '', newUrl);
    return true;
  }

  const storedToken = localStorage.getItem(TOKEN_KEY);
  return !!storedToken;
}

export function redirectToLogin(appName?: string): void {
  const currentUrl = encodeURIComponent(window.location.href);
  let authUrl = `${AUTH_BASE_URL}?redirect=${currentUrl}`;

  if (appName) {
    authUrl += `&app=${appName}`;
  }

  window.location.href = authUrl;
}

export async function validateAndRedirect(apiBaseUrl: string, appName?: string): Promise<boolean> {
  const token = localStorage.getItem(TOKEN_KEY);

  if (!token) {
    redirectToLogin(appName);
    return false;
  }

  try {
    const response = await fetch(`${apiBaseUrl}/api/auth/me`, {
      headers: {
        'Authorization': `Bearer ${token}`
      }
    });

    if (response.ok) {
      return true;
    }

    localStorage.removeItem(TOKEN_KEY);
    redirectToLogin(appName);
    return false;
  } catch (error) {
    console.error('Token validation failed:', error);
    return true; // Allow offline usage
  }
}

export function logout(appName?: string): void {
  localStorage.removeItem(TOKEN_KEY);
  localStorage.removeItem('current_username');
  redirectToLogin(appName);
}

export function getToken(): string | null {
  return localStorage.getItem(TOKEN_KEY);
}

Step 2: Initialize Authentication in App Entry

For React (App.tsx/main.tsx):

typescript

import { useEffect, useState } from 'react';
import { initAuth, validateAndRedirect } from './utils/authRedirect';

function App() {
  const [isAuthenticated, setIsAuthenticated] = useState(false);
  const [isLoading, setIsLoading] = useState(true);

  useEffect(() => {
    const checkAuth = async () => {
      initAuth();
      const isValid = await validateAndRedirect(
        import.meta.env.VITE_API_URL,
        'your-app-name' // Replace with your app identifier
      );
      setIsAuthenticated(isValid);
      setIsLoading(false);
    };
    checkAuth();
  }, []);

  if (isLoading) return <div>Loading...</div>;
  if (!isAuthenticated) return null; // Redirecting to login

  return <YourApp />;
}

For Vue (App.vue):

vue

<template>
  <div v-if="isLoading">Loading...</div>
  <YourApp v-else-if="isAuthenticated" />
</template>

<script setup>
import { ref, onMounted } from 'vue';
import { initAuth, validateAndRedirect } from './utils/authRedirect';

const isAuthenticated = ref(false);
const isLoading = ref(true);

onMounted(async () => {
  initAuth();
  const isValid = await validateAndRedirect(
    import.meta.env.VITE_API_URL,
    'your-app-name'
  );
  isAuthenticated.value = isValid;
  isLoading.value = false;
});
</script>

Step 3: Configure Environment Variables

Create .env file:

env

# Development
VITE_API_URL=http://localhost:3001
VITE_AUTH_URL=http://localhost:3001/auth

# Production (update with actual URLs)
# VITE_API_URL=https://api.forsion.com
# VITE_AUTH_URL=https://api.forsion.com/auth

API Integration

IMPORTANT: All API calls (except login/register) require the JWT token in the Authorization header. The frontend uses the token string (not JWT_SECRET) returned from login.

Setting Up API Client with Axios

typescript

import axios from 'axios';
import { getToken, logout } from './utils/authRedirect';

const apiClient = axios.create({
  baseURL: import.meta.env.VITE_API_URL,
});

// Request interceptor: Add token
apiClient.interceptors.request.use((config) => {
  const token = getToken();
  if (token) {
    config.headers.Authorization = `Bearer ${token}`;
  }
  return config;
});

// Response interceptor: Handle 401
apiClient.interceptors.response.use(
  (response) => response,
  (error) => {
    if (error.response?.status === 401) {
      logout('your-app-name');
    }
    return Promise.reject(error);
  }
);

export default apiClient;

Setting Up API Client with Fetch

typescript

import { getToken, logout } from './utils/authRedirect';

export async function apiFetch(endpoint: string, options: RequestInit = {}) {
  const token = getToken();
  const headers = {
    'Content-Type': 'application/json',
    ...options.headers,
  };

  if (token) {
    headers['Authorization'] = `Bearer ${token}`;
  }

  try {
    const response = await fetch(
      `${import.meta.env.VITE_API_URL}${endpoint}`,
      { ...options, headers }
    );

    if (response.status === 401) {
      logout('your-app-name');
      throw new Error('Unauthorized');
    }

    return response;
  } catch (error) {
    throw error;
  }
}

Key API Endpoints

Authentication Endpoints

Endpoint	Method	Purpose	Auth Required
`/api/auth/login`	POST	Username/email/phone + password login	No
`/api/auth/login-sms`	POST	Phone + verification code login	No
`/api/auth/register`	POST	Register new user (requires invite code)	No
`/api/auth/send-code`	POST	Send SMS verification code	No
`/api/auth/reset-password`	POST	Reset password via SMS code	No
`/api/auth/me`	GET	Get current user info	Yes
`/api/auth/password`	PUT	Change password	Yes

Login Request Examples

Password Login:

typescript

const response = await fetch(`${API_URL}/api/auth/login`, {
  method: 'POST',
  headers: { 'Content-Type': 'application/json' },
  body: JSON.stringify({
    identifier: 'user@example.com', // or username or phone
    password: 'password123'
  })
});
const { token, user } = await response.json();

SMS Verification Code Login:

typescript

// 1. Send code
await fetch(`${API_URL}/api/auth/send-code`, {
  method: 'POST',
  headers: { 'Content-Type': 'application/json' },
  body: JSON.stringify({
    target: '13800138000',
    type: 'phone',
    purpose: 'login'
  })
});

// 2. Login with code
const response = await fetch(`${API_URL}/api/auth/login-sms`, {
  method: 'POST',
  headers: { 'Content-Type': 'application/json' },
  body: JSON.stringify({
    phone: '13800138000',
    code: '123456'
  })
});
const { token, user } = await response.json();

Registration:

typescript

const response = await fetch(`${API_URL}/api/auth/register`, {
  method: 'POST',
  headers: { 'Content-Type': 'application/json' },
  body: JSON.stringify({
    email: 'newuser@example.com',
    password: 'password123',
    invite_code: 'INVITE123'
  })
});
const { token, user } = await response.json();

Authentication Flow

code

┌─────────────────────────────────────────────────────────┐
│ User visits your frontend app                           │
└─────────────────────────────────────────────────────────┘
                        │
                        ▼
          ┌─────────────────────────┐
          │ Check local token       │
          │ (localStorage)          │
          └─────────────────────────┘
                        │
        ┌───────────────┴───────────────┐
        │                               │
        ▼                               ▼
┌───────────────┐             ┌─────────────────┐
│ Token exists  │             │ Token missing   │
└───────────────┘             └─────────────────┘
        │                               │
        ▼                               ▼
┌───────────────┐             ┌─────────────────────────────┐
│ Validate      │             │ Redirect to Forsion login   │
│ GET /auth/me  │             │ /auth?redirect=current_url  │
└───────────────┘             └─────────────────────────────┘
        │                               │
   ┌────┴────┐                          ▼
   │         │                  ┌─────────────────┐
   ▼         ▼                  │ User logs in    │
┌──────┐  ┌──────┐              └─────────────────┘
│Valid │  │Invalid                       │
└──────┘  └──────┘                       ▼
   │         │              ┌─────────────────────────────┐
   ▼         ▼              │ Redirect back with token    │
┌──────┐  ┌───────────┐    │ ?token=xxx                  │
│Enter │  │Clear token│    └─────────────────────────────┘
│ App  │  │Redirect   │                 │
└──────┘  └───────────┘                 ▼
                          ┌─────────────────────────────┐
                          │ App saves token             │
                          │ Clears URL param            │
                          └─────────────────────────────┘

Common Issues & Solutions

Issue: 401 Unauthorized on API Calls

Symptoms: API returns 401 even with token present

Solutions:

•Check token is being sent in header: Authorization: Bearer <token> (use the token string from login response, NOT JWT_SECRET)
•Verify token hasn't expired (default: 7 days)
•Check token format (no extra spaces or quotes)
•Verify API base URL is correct
•Ensure you're using the token (e.g., eyJhbGciOiJIUzI1NiIs...), not the JWT_SECRET from backend

Issue: Token Not Saved After Login

Symptoms: User redirected back but not authenticated

Solutions:

•Verify initAuth() is called on app mount
•Check URL parameter name is token (lowercase)
•Check localStorage is accessible (not blocked by browser)
•Verify auth_token key in localStorage

Issue: CORS Errors

Symptoms: Network requests fail with CORS errors

Solutions:

•Backend must include your frontend origin in CORS allowlist
•Contact backend admin to add your domain
•Development: Check http://localhost:<port> is allowed
•Production: Ensure your domain is in backend's ALLOWED_ORIGINS

Issue: Infinite Redirect Loop

Symptoms: App keeps redirecting between login and main app

Solutions:

•Ensure validateAndRedirect only runs once on mount
•Check token validation endpoint /api/auth/me is accessible
•Verify network errors don't trigger unnecessary redirects
•Add loading state to prevent re-execution

Issue: SMS Verification Code Not Received

Symptoms: Code sending succeeds but SMS not received

Solutions:

•Check phone number format (China: 11 digits, starts with 1)
•Wait 60 seconds between requests (rate limiting)
•Check spam/blocked messages on phone
•Development: Check server logs for generated code
•Verify backend SMS service (Aliyun) is configured

Advanced Configurations

Multi-Tab Synchronization

Sync login state across browser tabs:

typescript

window.addEventListener('storage', (e) => {
  if (e.key === 'auth_token') {
    if (!e.newValue) {
      // Token removed in another tab, logout
      window.location.href = '/login';
    } else {
      // Token updated, refresh auth state
      validateAndRedirect(import.meta.env.VITE_API_URL, 'your-app');
    }
  }
});

Custom Logout Handler

typescript

export async function logoutWithCleanup(appName?: string) {
  // Call backend logout endpoint (optional)
  try {
    await fetch(`${API_URL}/api/auth/logout`, {
      method: 'POST',
      headers: {
        'Authorization': `Bearer ${getToken()}`
      }
    });
  } catch (error) {
    console.error('Logout request failed:', error);
  }

  // Clear all local storage
  localStorage.removeItem('auth_token');
  localStorage.removeItem('current_username');
  localStorage.removeItem('user_info');

  // Clear session storage
  sessionStorage.clear();

  // Redirect to login
  redirectToLogin(appName);
}

Protected Route Component (React)

typescript

import { Navigate } from 'react-router-dom';
import { getToken } from './utils/authRedirect';

export function ProtectedRoute({ children }: { children: React.ReactNode }) {
  const token = getToken();

  if (!token) {
    return <Navigate to="/login" replace />;
  }

  return <>{children}</>;
}

// Usage in router
<Route path="/dashboard" element={
  <ProtectedRoute>
    <Dashboard />
  </ProtectedRoute>
} />

Protected Route (Vue Router)

typescript

import { getToken } from './utils/authRedirect';

router.beforeEach((to, from, next) => {
  const requiresAuth = to.matched.some(record => record.meta.requiresAuth);
  const token = getToken();

  if (requiresAuth && !token) {
    next({ name: 'Login', query: { redirect: to.fullPath } });
  } else {
    next();
  }
});

App Identifiers

When calling auth functions, use these standard app identifiers:

Application	Identifier	Description
AI Studio	`ai-studio`	AI conversation app
Desktop	`desktop`	Desktop application
Calendar	`calendar`	Calendar app
Photo Studio	`photo-studio`	Photo editing app
Custom App	Use project name	Use kebab-case project name

Best Practices

•Error Handling: Always wrap auth calls in try-catch
•Loading States: Show loading UI during validation
•Offline Support: Allow graceful degradation when API unavailable
•
Security:
- •Never log tokens in production
- •Never store JWT_SECRET in frontend (it belongs only on backend)
- •Only use the token string from login response
•Token Refresh: Implement token refresh if using long sessions
•Testing: Test login flow in incognito/private mode

Backend Configuration Requirements

For integration to work, backend admin must:

•

Add your origin to CORS allowlist in backend .env:

env

ALLOWED_ORIGINS=http://localhost:5173,https://your-app.com

•
Verify these endpoints are accessible:
- •/auth (login page - public)
- •/api/auth/login (login API)
- •/api/auth/register (registration API)
- •/api/auth/me (user info API)
•
Backend JWT configuration (backend only, not shared with frontend):
env
```
JWT_SECRET=your-secret-key-kept-on-backend-only
JWT_EXPIRES_IN=7d
```
Note: JWT_SECRET stays on the backend server. Frontend never receives or configures this secret.

Additional Resources

For more detailed information, refer to the Forsion backend documentation:

•Complete API reference: /docs/API.md
•Backend integration guide: /docs/CLIENT_INTEGRATION.md
•Login system architecture: /Documents/登录系统/统一登录系统实现方案.md
•SMS service setup: /Documents/登录系统/阿里云短信服务配置指南.md

Quick Checklist

Before deploying:

• authRedirect.ts utility created
• Auth check on app mount
• Environment variables configured
• API client with auth interceptors
• 401 error handling implemented
• Logout functionality working
• CORS configured on backend
• App identifier chosen
• Tested in clean browser session

Summary

This skill provides everything needed to integrate the Forsion unified login system:

•Copy authRedirect.ts utility
•Call initAuth() and validateAndRedirect() on app mount
•Configure API client with token interceptors
•Handle 401 errors with logout
•Test thoroughly

The integration enables seamless authentication across all Forsion applications with automatic token management and unified login experience.
