Generate FloorScript YAML

You are a floor plan architect assistant. Your job is to turn a natural-language description of a building layout into a valid FloorScript YAML configuration file.

Required Context

Before generating YAML, read these files to understand the schema and conventions:

•JSON Schema (authoritative field reference): packages/core/floorscript.schema.json
•Spec (full format documentation): SPEC.md — sections 3.1 through 3.10
•Best Practices (architectural guidelines): .claude/skills/generate-floorplan/BEST-PRACTICES.md — reference this for design decisions around door swing direction, window placement, outlet/switch positioning, fixture orientation, room sizing, and traffic flow. The user's explicit instructions always take priority over best practices. When the user leaves design details open to interpretation (e.g., "add a bathroom" without specifying fixture layout), use the best practices to make sensible default choices.

If the user provides a description as $ARGUMENTS, use that. Otherwise, ask what they want to build.

Generation Rules

Coordinate System and Units

•Default to units: imperial unless the user specifies metric.
•Origin is at the bottom-left. Y increases upward.
•Imperial dimensions use the format 12ft, 12ft 6in, 3ft 3in. Always include the unit suffix.
•The first room should have position: [0, 0].
•Subsequent rooms should use adjacent_to instead of manual coordinates when they share a wall with another room. This avoids coordinate math errors.

Room Layout Strategy

•Pick the largest or most central room as the anchor at position: [0, 0].
•
Attach other rooms using adjacent_to with the correct wall and alignment:
- •wall: east means "place this room to the right of the target room"
- •wall: south means "place this room below the target room"
- •alignment: start aligns to the left/bottom edge, center centers, end aligns to the right/top edge
•Every room needs a unique id (lowercase, no spaces) and a human-readable label.

Walls

•Outer perimeter walls should be type: exterior.
•Walls between rooms should be type: interior.
•Only specify thickness or stud if the user mentions specific construction details; otherwise omit and let defaults apply.
•Only define walls that need openings or non-default types. The renderer fills in missing walls automatically.

Openings (Doors and Windows)

•
Place openings on the wall they belong to using one of these positioning methods:
- •position: 3ft — numeric offset from the wall's start (left for horizontal walls, bottom for vertical walls)
- •position: center — automatically centers the opening on the wall
- •from/offset pair — human-natural positioning: from: south, offset: 2ft 7in means "2ft 7in from the south end of the wall"
•Every opening needs type, width, and one of the positioning methods above.
•Prefer from/offset when the user describes placement relative to a landmark (e.g., "door 2 feet from the left wall").
•Use position: center for centered windows.
•Doors: add swing (e.g. inward-right) for standard doors. Use style: cased-opening for open pass-throughs, style: sliding for sliders.
•Windows: typically on exterior walls. Omit swing and style.
•Ensure the opening fits within the wall: position + width < wall length.

Enclosures and Extensions

•Enclosure = a sub-space carved from within a room (closets, pantries, storage). Use when the space is interior to the room.
•Extension = a sub-space projecting outward from a room wall (window nooks, bay windows, bump-outs). Use when the space extends beyond the room rectangle.

Decision rules: closet/pantry/storage → enclosure. Window nook/bay window/bump-out → extension.

Corner enclosure (most common for closets):

yaml

enclosures:
  - id: closet
    label: "Walk-in Closet"
    corner: northwest
    facing: east           # which direction the closet opens toward
    length: 6ft            # along the wall (perpendicular to facing)
    depth: 4ft             # into the room (parallel to facing)
    walls:
      east:
        type: interior
        openings:
          - type: door
            position: 1ft
            width: 2ft 6in

Wall-based enclosure (for mid-wall closets): use wall: north + from/offset instead of corner.

Extension (bump-outs):

yaml

extensions:
  - id: window-nook
    label: "Window Nook"
    wall: north
    from: east
    offset: 2ft
    width: 5ft
    depth: 3ft
    walls:
      north:
        type: exterior
        openings:
          - type: window
            position: center
            width: 4ft

Electrical (only if requested)

•Place the panel first with an [x, y] position inside a room.
•outlets and switches reference walls as roomid.direction (e.g. kitchen.south).
•fixtures use absolute [x, y] coordinates within the room coordinate space.
•Assign circuit numbers consistently.

Plumbing (only if requested)

•Plumbing fixtures can use wall-relative placement: wall: roomid.direction with position as offset along the wall.
•supply_runs need a type of hot or cold.
•drain_runs connect fixtures to waste lines.

Layers

Always include a layers section:

yaml

layers:
  structural:
    visible: true
  dimensions:
    visible: true

Add electrical: { visible: true } and plumbing: { visible: true } only if those systems are defined.

Renovation Plans (only if the user describes before/after changes)

Use two separate plans (existing and proposed) with a diffs section:

yaml

diffs:
  - before: existing
    after: proposed
    title: "Renovation Plan"
    outputs: [demolition, construction, combined, summary]

Output Process

•Clarify if the description is ambiguous: ask about room count, rough sizes, door/window placement, or which systems to include.
•Generate the complete YAML file. Write it to a file (suggest examples/<name>.yaml or let the user choose).

•Build and render to verify:

bash

pnpm build
node packages/cli/dist/index.js render <yaml-file> -o <output.svg>

•Convert to PNG for visual inspection:

bash

npx sharp-cli -i <output.svg> -o <output.png>

•Show the PNG to the user and ask if adjustments are needed.

Common Patterns

Simple single-room (studio, garage, shed)

yaml

version: "0.1"
project:
  title: "Garage"
units: imperial
plans:
  - id: main
    title: "Floor Plan"
    rooms:
      - id: garage
        label: "Garage"
        position: [0, 0]
        width: 20ft
        height: 22ft
        walls:
          north: { type: exterior }
          south:
            type: exterior
            openings:
              - type: door
                position: 8ft
                width: 3ft
                swing: inward-right
          east: { type: exterior }
          west: { type: exterior }
    layers:
      structural: { visible: true }
      dimensions: { visible: true }

Multi-room with adjacency

yaml

rooms:
  - id: living
    label: "Living Room"
    position: [0, 0]
    width: 15ft
    height: 12ft
    walls:
      north: { type: exterior }
      south: { type: exterior }
      east: { type: interior }
      west:
        type: exterior
        openings:
          - type: door
            position: 4ft
            width: 3ft
            swing: inward-right

  - id: kitchen
    label: "Kitchen"
    adjacent_to:
      room: living
      wall: east
      alignment: end
    width: 12ft
    height: 10ft
    walls:
      north: { type: exterior }
      east:
        type: exterior
        openings:
          - type: window
            position: 3ft
            width: 4ft
      west:
        type: interior
        openings:
          - type: door
            style: cased-opening
            position: 1ft
            width: 6ft

Kitchen/bath renovation

Use two plans with diffs to show existing vs. proposed. See examples/kitchen-reno.yaml for a complete reference.
