GF-Viz: Terminal Visualization

Renders .gateflow/map/ data as interactive ASCII/Unicode diagrams in the terminal.

Prerequisites

Check for codebase map:

bash

ls .gateflow/map/CODEBASE.md 2>/dev/null

•Map exists: Proceed to render
•No map: Tell user: "No codebase map found. Run /gf-map first to generate one."

Entry Point

When invoked, render the Overview Dashboard and present the navigation menu.

If invoked with an argument (e.g., /gf-viz uart_tx), jump directly to the Module Detail Card for that module.

View 1: Overview Dashboard

Data sources: CODEBASE.md (stats, module index), hierarchy.md (tree), fsm.md (FSM list), clock-domains.md (clocks/CDC)

Read these files, extract the data, and render:

code

╔══ CODEBASE: <project_name> ═══════════════════════════════╗
║                                                            ║
║  ● N modules  ● N packages  ● N FSMs  ● N interfaces       ║
║  ● N clocks   ● N CDC       ● N ports   ● N warnings       ║
║                                                            ║
╠══ HIERARCHY (compact) ════════════════════════════════════╣
║                                                            ║
║  ◆ <top> ──┬── <child1> ──┬── <grandchild1>               ║
║            │              └── <grandchild2>                ║
║            └── <child2> ── <grandchild3>                   ║
║                                                            ║
╠══ FSMs ═══════════════════════════════════════════════════╣
║  ↻ <fsm_name> (<module>)  N states: S1→S2→S3→S4           ║
║  ↻ <fsm_name> (<module>)  N states: S1→S2→S3              ║
║                                                            ║
╠══ HEALTH ═════════════════════════════════════════════════╣
║  <✓ or ⚠> lint status  <✓ or ⚠> undriven  <✓ or ⚠> CDC   ║
║                                                            ║
╠═══════════════════════════════════════════════════════════╣
║  [1] Hierarchy  [2] FSMs  [3] Module detail                ║
║  Or ask anything: "show uart_tx", "trace data path"        ║
╚═══════════════════════════════════════════════════════════╝

Rules:

•Hierarchy flattened to 2 levels max in dashboard
•FSMs show one-line summaries with state chain
•Stats pulled from CODEBASE.md frontmatter and module index
•Health pulled from warnings section
•If any section has no data, show "none detected" rather than omitting

View 2: Hierarchy Explorer

Data sources: hierarchy.md, modules/*.md

code

══ MODULE HIERARCHY ════════════════════════════════════════

◆ <top_module>                                       TOP
├── ■ <inst> : <module> [PARAM=VAL]                   MID
│   ├── ■ <inst> : <module>                           MID
│   │   ├── □ <inst> : <module>                       LEAF
│   │   └── □ <inst> : <module>                       LEAF
│   └── □ <inst> : <module> [W=32, D=16]              LEAF
└── ■ <inst> : <module>                               MID
    └── □ <inst> : <module>                           LEAF

── STATS ──────────────────────────────────────────────
  Total: N modules │ Max depth: N │ Leaf count: N

── INSTANCE TABLE ─────────────────────────────────────
  ┃ Parent       │ Instance   │ Module          │ Params       ┃
  ┃ ...          │ ...        │ ...             │ ...          ┃

═══════════════════════════════════════════════════════════
  [H] Home  [2] FSMs  [3] Module detail: <name>
  Or: "show <module>", "which modules use <module>?"

Module type badges:

•◆ TOP - bold, top-level module (never instantiated by others)
•■ MID - standard weight, has children
•□ LEAF - lighter weight, no children

Depth cues: Deeper modules rendered with lighter visual weight. Top pops, leaves fade.

Behaviors:

•Show full tree with all depth levels
•Parameters shown inline as [PARAM=VAL]
•Instance table shows all parent→child relationships
•"show <module>" re-renders tree rooted at that module
•"which modules use <module>?" searches instance table, lists parents

View 3: FSM Viewer

Data sources: fsm.md, per-module pages

When multiple FSMs exist, show picker first:

code

══ STATE MACHINES ══════════════════════════════════════════

  [1] ↻ <fsm_name>  (<module>)   N states
  [2] ↻ <fsm_name>  (<module>)   N states
  [3] ↻ <fsm_name>  (<module>)   N states

  Pick a number, or: "show <fsm_name>"

Single FSM rendering:

code

══ FSM: <fsm_name> ═════════════════════════════════════════
   Module: <module> │ Encoding: N-bit │ Reset: → <reset_state>

                    <condition>
   ┌──────┐  ─────────────►  ┌───────┐
   │      │                  │       │
   │  S1  │                  │  S2   │
   │  ◉   │                  │       │
   └──────┘                  └───┬───┘
      ▲                          │ <condition>
      │                          ▼
   ┌──────┐                  ┌───────┐
   │      │  ◄───────────   │       │──┐
   │  S4  │   <condition>   │  S3   │  │ <self-loop cond>
   │      │                  │       │◄─┘
   └──────┘                  └───────┘

── TRANSITIONS ────────────────────────────────────────────
  ┃ From  │ To    │ Condition     │ Output          ┃
  ┃ S1    │ S2    │ ...           │ ...             ┃
  ┃ S2    │ S3    │ ...           │ ...             ┃
  ┃ ...   │ ...   │ ...           │ ...             ┃

── STATE DETAILS ──────────────────────────────────────────
  ◉ S1   Reset state. <description>
    S2   <description>
    S3   <description>
    S4   <description>

═══════════════════════════════════════════════════════════
  [H] Home  [1] Hierarchy  [3] Module: <parent_module>
  Or: "show another FSM", "explain the S2→S3 transition"

Layout rules for FSM box diagrams:

•2-4 states: Arrange in a line or L-shape
•4-6 states: Arrange in a 2x2 or 2x3 grid
•7+ states: Use transition table only (too complex for ASCII boxes)
•Reset state always marked with ◉
•Self-loops shown as ──┐ / ◄─┘ back to same box
•Transition arrows use ──► with condition labels

Behaviors:

•"explain <from>→<to> transition" triggers analysis using RTL source
•"show module" cross-links to parent module's detail card
•Output column in transition table filled when map data includes it

View 4: Module Detail Card

Data sources: modules/<module_name>.md (primary), hierarchy.md, fsm.md, signals.md

code

╔══════════════════════════════════════════════════════════╗
║  <module_name>                              <TYPE_BADGE> ║
║  <file_path>:<line_range>                                ║
╠══ PARAMETERS ════════════════════════════════════════════╣
║  ┃ Name     │ Type │ Default     │ Description       ┃  ║
║  ┃ ...      │ ...  │ ...         │ ...               ┃  ║
╠══ PORTS ═════════════════════════════════════════════════╣
║  → <name>     input   <width>   <description>           ║
║  → <name>     input   <width>   <description>           ║
║  ← <name>     output  <width>   <description>           ║
║  ← <name>     output  <width>   <description>           ║
╠══ INTERNALS ═════════════════════════════════════════════╣
║                                                          ║
║  Clock : <clock_name> (<domain info>)                    ║
║  Reset : <reset_name> (<type>)                           ║
║  FSM   : ↻ <fsm_name> → <state_list>                    ║
║  Inst  : <instance_count> (<list or "none (leaf)")>      ║
║                                                          ║
╠══ CONNECTIONS ═══════════════════════════════════════════╣
║                                                          ║
║  Instantiated by:                                        ║
║    ■ <parent_module> as <instance_name>                  ║
║      .<port>(<signal>) .<port>(<signal>)                 ║
║      .<port>(<signal>) .<port>(<signal>)                 ║
║                                                          ║
╠══ HEALTH ════════════════════════════════════════════════╣
║  <✓ or ⚠> port connection status                         ║
║  <✓ or ⚠> lint status                                    ║
║  <✓ or ⚠> assertion coverage                             ║
║                                                          ║
╚══════════════════════════════════════════════════════════╝
  [H] Home  [1] Hierarchy  [2] FSM: <fsm_name>
  [↑] Parent: <parent_module>
  Or: "show ports", "explain the handshake", "add assertions"

Port direction symbols:

•→ inputs
•← outputs
•↔ bidirectional (inout)

Type badges: TOP, MID, LEAF

Behaviors:

•Connections section shows actual signal bindings from parent instantiation
•If module is instantiated multiple times, show each instance
•FSM line cross-links to FSM viewer
•Parent name cross-links to parent's detail card
•"add assertions" can hand off to sv-verification agent
•"explain the handshake" reads RTL source to reason about protocol

Color/Emphasis Vocabulary

Apply these consistently across all views:

Element	Symbol	Style
Top module	`◆`	Bold
Mid module	`■`	Standard
Leaf module	`□`	Light
Input port	`→`	Green emphasis
Output port	`←`	Yellow emphasis
Bidir port	`↔`	Cyan emphasis
FSM indicator	`↻`	Standard
Reset state	`◉`	Bold/highlighted
Clean/pass	`✓`	Green
Warning	`⚠`	Yellow/amber
Info/stat	`●`	Standard
Transition	`──►`	Standard

Depth cues in hierarchy: Top-level bold, mid standard, leaf dimmed.

Interaction Model

Menu Navigation

After every render, show a navigation footer with numbered options:

•[H] Home - return to dashboard
•[1] [2] [3] - switch between views
•[↑] Parent - navigate up in hierarchy (detail card only)

Free-Form Queries

Always accept natural language alongside menus:

•"show <module_name>" → Module Detail Card
•"show <fsm_name>" → FSM Viewer for that FSM
•"which modules use <module>?" → filtered hierarchy
•"trace <signal> from <module_a> to <module_b>" → signal path analysis
•"explain <aspect>" → reads RTL source, reasons about it
•"add assertions to <module>" → hands off to sv-verification agent
•"back" → previous view
•"home" → dashboard

Agent Handoff

For queries that go beyond visualization:

•"explain" / "why" → spawn sv-understanding agent via Task tool
•"add assertions" → spawn sv-verification agent via Task tool
•"fix" / "refactor" → spawn sv-refactor agent via Task tool

When handing off, pass the current visualization context (which module, which view) so the agent has full context.

Auto-Trigger After /gf-map

When used as a final step in gf-architect, render ONLY the Overview Dashboard (View 1) as a compact summary. Do not show the full interactive menu - just the dashboard with a note:

code

Run /gf-viz to explore interactively.

Data Extraction

Reading CODEBASE.md

Extract from frontmatter:

•total_files, total_tokens, commit, last_mapped

Extract from Module Index table:

•Module names, types, files, port summaries

Extract from Warnings section:

•Lint warnings, undriven signals, CDC issues

Reading hierarchy.md

Extract from Mermaid flowchart:

•Parent→child relationships
•Instance names

Extract from Instance Table:

•Full parent, instance, module, parameters data

Reading fsm.md

Extract for each FSM:

•FSM name, parent module
•State list with encoding
•Transition table (from, to, condition, output)
•Reset state

Reading modules/*.md

Extract per module:

•Parameters table
•Ports table (name, direction, width, description)
•Clock/reset info
•Instance list
•Assertion/coverage info

Edge Cases

•Empty map: "No codebase map found. Run /gf-map first."
•No FSMs detected: FSM section shows "No state machines detected in this codebase."
•Single module: Hierarchy view shows just the one module. Skip instance table.
•Module not found: "Module '<name>' not found in map. Available modules: <list>"
•Very deep hierarchy (>6 levels): Render full tree but note: "Deep hierarchy detected. Use 'show <module>' to focus on a subtree."
•Very wide hierarchy (>10 siblings): Show first 8, then "... and N more. Use 'show <parent>' to see all."
