Docker to Kustomize Converter

Transforms Docker commands or Docker Compose files into Kubernetes Kustomize manifests and ArgoCD Application Ansible playbooks.

When to use

•When migrating from Docker containers to Kubernetes
•When creating new ArgoCD Applications for existing Docker services
•When standardizing container deployments across the cluster

Prerequisites

•Docker command with --name, -p (ports), -v (volumes), and image reference
•Or Docker Compose file with services, ports, volumes, and image configuration

Input format

Docker run command example

bash

docker run -d \
  --name rustfs \
  -p 9000:9000 \
  -p 9001:9001 \
  -v /data:/data \
  rustfs/rustfs:latest

Docker Compose example

yaml

services:
  rustfs:
    image: rustfs/rustfs:latest
    container_name: rustfs
    ports:
      - "9000:9000"
      - "9001:9001"
    volumes:
      - /data:/data
    restart: unless-stopped

Transformation process

1. Parse input

Extract from Docker command:

•Image: rustfs/rustfs:latest (last argument)
•Name: --name rustfs (container name for deployment name)
•Ports: -p 9000:9000 -p 9001:9001 (host:container mapping)
•Volumes: -v /data:/data (host:container path mapping)

Extract from Docker Compose:

•Image: image: field from service
•Name: container_name: or derive from service name
•Ports: ports: array (format: "host:container")
•Volumes: volumes: array (format: "host:container:options")

2. Create Kustomize base

Create directory structure:

code

kustomize/<app-name>/
├── base/
│   ├── kustomization.yaml
│   ├── deployment.yaml
│   ├── service.yaml
│   └── pvc.yaml
└── overlays/
    └── prod/
        └── kustomization.yaml

3. Generate deployment.yaml

yaml

apiVersion: apps/v1
kind: Deployment
metadata:
  name: <app-name>
  labels:
    app: <app-name>
spec:
  replicas: 1
  selector:
    matchLabels:
      app: <app-name>
  template:
    metadata:
      labels:
        app: <app-name>
    spec:
      containers:
        - name: <app-name>
          image: IMAGE_PLACEHOLDER
          ports:
            - containerPort: <container-port-1>
              name: http-<app-name>-1
            - containerPort: <container-port-2>
              name: http-<app-name>-2
          # Add more ports if needed
          volumeMounts:
            - name: <app-name>-data
              mountPath: <container-volume-path>
      volumes:
        - name: <app-name>-data
          persistentVolumeClaim:
            claimName: <app-name>-data

4. Generate service.yaml

yaml

apiVersion: v1
kind: Service
metadata:
  name: <app-name>
spec:
  selector:
    app: <app-name>
  ports:
    - protocol: TCP
      port: <host-port-1>
      targetPort: <container-port-1>
      name: http-<app-name>-1
    - protocol: TCP
      port: <host-port-2>
      targetPort: <container-port-2>
      name: http-<app-name>-2
  type: ClusterIP

5. Generate pvc.yaml

yaml

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: <app-name>-data
spec:
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 1Gi

6. Generate base kustomization.yaml

yaml

apiVersion: kustomize.config.k8s.io/v1beta1
kind: Kustomization

resources:
- deployment.yaml
- service.yaml
- pvc.yaml

7. Generate overlay kustomization.yaml

yaml

apiVersion: kustomize.config.k8s.io/v1beta1
kind: Kustomization

namespace: <app-name>

images:
- name: IMAGE_PLACEHOLDER
  newName: <image-name>
  newTag: <image-tag>

resources:
- ../../base

8. Generate ArgoCD Application Ansible playbook

Create addons/<app-name>.yaml with:

yaml

- hosts: k8s-control-plane-1
  gather_facts: no
  become: no
  vars:
    namespace: <app-name>
  tasks:

    - name: Deploy <app-name> ArgoCD Application
      kubernetes.core.k8s:
        state: present
        definition:
          apiVersion: argoproj.io/v1alpha1
          kind: Application
          metadata:
            name: <app-name>
            namespace: argocd
            finalizers:
              - resources-finalizer.argocd.argoproj.io
          spec:
            project: default
            source:
              repoURL: https://github.com/codesenju/kubelab.git
              path: kustomize/<app-name>/overlays/prod
              targetRevision: main
              kustomize:
                commonAnnotations:
                  argocd.argoproj.io/sync-options: SkipDryRunOnMissingResource=true
                labels:
                  app.kubernetes.io/instance: <app-name>-prod
            destination:
              server: https://kubernetes.default.svc
              namespace: '{{ namespace }}'
            syncPolicy:
              automated:
                prune: true
                selfHeal: true
              syncOptions:
                - CreateNamespace=true
                - ServerSideApply=true
                - RespectIgnoreDifferences=true
      tags: <app-name>

Output

The skill will create:

•Kustomize base directory with deployment, service, PVC, and kustomization files
•Kustomize overlay directory with production kustomization
•Ansible playbook in addons/<app-name>.yaml

Usage example

Input:

bash

docker run -d \
  --name rustfs \
  -p 9000:9000 \
  -p 9001:9001 \
  -v /data:/data \
  rustfs/rustfs:latest

Generated files:

•kustomize/rustfs/base/kustomization.yaml
•kustomize/rustfs/base/deployment.yaml
•kustomize/rustfs/base/service.yaml
•kustomize/rustfs/base/pvc.yaml
•kustomize/rustfs/overlays/prod/kustomization.yaml
•addons/rustfs.yaml

Notes

•Default replica count is 1 (adjust based on requirements)
•Default storage request is 1Gi (adjust based on requirements)
•Service type defaults to ClusterIP
•PVC access mode defaults to ReadWriteOnce
•All resources use consistent naming: <app-name> for deployment/service, <app-name>-data for PVC
•Image placeholder pattern: IMAGE_PLACEHOLDER replaced in overlay with actual image reference
